Page 1: User Manual
USER MANUAL ISIS PC/104-PLUS SINGLE BOARD COMPUTER Issue E - September 2009 - ETH_ISIS_USM DIGITAL TECHNOLOGIES FOR A BETTER WORLD www.eurotech.com... - Page 2 The warranty on all third party manufactured products utilised by Eurotech is limited to 1 year. Eurotech will make all reasonable effort to repair the product or replace it with an identical variant. Eurotech reserves the right to replace the returned product with an alternative variant or an equivalent fit, form and functional product.
-
Page 3: Table Of Contents
Contents Contents Handling your board safely ......................5 Conventions............................5 Introduction .............................6 ISIS features ...........................7 CPU module........................7 ISIS PC/104-Plus board .....................7 Software specification........................9 Operating system support ....................9 Drivers..........................9 BIOS ..........................9 Getting started with your ISIS .......................10 Identifying your ISIS version.....................10 Connecting a hard disk drive....................10 Connecting a SDIO card .................... - Page 4 Appendix B – ISIS cable kit ......................50 Adapter boards ........................ 50 Cables..........................51 Appendix C – Ethernet adaptor schematic ................... 55 Appendix D – Reference information.................... 56 Appendix E – RoHS Compliance....................57 Eurotech Group Worldwide presence................... 59 Issue E...
-
Page 5: Handling Your Board Safely
This includes storing the board in appropriate anti- static packaging and wearing a wrist strap when handling the board. Packaging Please ensure that, should a board need to be returned to Eurotech, it is adequately packed, preferably in the original packing material. Electromagnetic compatibility (EMC) -
Page 6: Introduction
GPS receiver (optional). Two serial ports. User definable GPIO. SMBUS/I2C. One SDIO socket. The ISIS board is available in the following variants: ISIS-1.6-M1G-F2G-GPS ISIS-1.6-M1G-F2G ISIS-1.1-M512-F2G-GPS ISIS XL-1.33-M1G-F2G-GPS-I ISIS XL-1.33-M1G-F2G-I ISIS XL-1.1-M512-F2G-GPS-I ... -
Page 7: Isis Features
ISIS features ISIS features CPU module Processor Intel Atom processor (13x13mm BGA): 1.6GHz TDP: 2W, or 1.1GHz TDP: 2W. Chipset Intel US15W SCH (22mmx22mm BGA): Premium TDP: 2.3W. System memory DDR2 SDRAM: up to 1GB (400/533 MHz). BIOS ... -
Page 8: Usb Support
ISIS user manual Audio HD Audio digital signals on a pin header. USB support USB 2.0 supporting low/full/high speed modes. Eight user accessible ports (on pin headers). Ethernet One fast Ethernet port supporting 10/100 BaseT. SuperIO ... -
Page 9: Software Specification
21, the PC/104 drivers require modification to accommodate the I/O base address offset of 0x3000. BIOS The ISIS incorporates a custom system BIOS developed by Eurotech which is based on the InsydeH2O core from Insyde Software, www.insydesw.com/products/products-efi- h2o.htm. -
Page 10: Getting Started With Your Isis
ISIS user manual Getting started with your ISIS Once you have a working ISIS system, you can start adding other peripherals to enable you to start development. This section guides you through setting up and using peripherals and some of the features of the ISIS. The ISIS is based on the InsydeH2O BIOS to provide support for the board as standard. -
Page 11: Connecting A Sdio Card
Getting started with your ISIS Connecting a SDIO card ® The ISIS has a single SDIO socket that supports MMC4.0 and SDIO1.1 specifications. This provides support for data storage and I/O cards such as Bluetooth and IEEE802.11b (WiFi). For more information see: www.sdcard.org/developers/tech/sdio/. The SDIO card can only be inserted into the socket one way. -
Page 12: Using The Battery Or Supercap
ISIS user manual Using the battery or supercap The external battery connection is provided on a 18-way connector (J4 - Multifunction and VGA connector). The battery is provided in the ISIS development kit. An optional supercap is provided on-board in cases where the external battery is not available. -
Page 13: Using The Audio Features
Getting started with your ISIS Using the audio features The ISIS provides an HD audio digital interface on a multifunction 20-way boxed header (J14), see page for connector details. A breakout board and a suitable cable are provided in the development kit. A breakout board (ISIS-HDA) contains HD audio codec (Analogue Devices AD1986A). -
Page 14: Using The Usb Ports
ISIS user manual Using the USB ports The ISIS provides eight user accessible USB2.0 ports. They are available on boxed headers (J16 – ports 0/1/4/5, J7 – ports 2/3, J14 – ports 6A/6B). See pages 40, for connector details. USB port 2 can be configured as host or client port using the BIOS setup utility. The OS boot from the USB mass storage devices is supported. -
Page 15: Using The Pc/104-Plus Expansion Bus
Getting started with your ISIS Using the PC/104-Plus expansion bus PC/104-Plus modules can be used with the ISIS to add extra functionality to the system. This interface supports 5V and 3.3V signalling, 33MHz 32-bit PCI bus peripherals that conform to the PC/104-Plus specification. To use a PC/104-Plus peripheral module with the ISIS, plug it into J3. -
Page 16: System Resources
ISIS user manual System resources PCI Devices and functions Device Function Function description Host Bridge Integrated Graphics & Video Device USB Client HD Audio Controller PCI Express Port 1 PCI Express Port 2 USB Classic UHCI Controller 1 USB Classic UHCI Controller 2 USB Classic UHCI Controller 3 USB2 EHCI Controller SDIO/MMC Port 1... - Page 17 System resources IO location Functional block [00000065 - 00000065] Motherboard resources [00000067 - 00000067] Motherboard resources [00000070 - 00000077] System CMOS/RTC [00000080 - 00000083] Motherboard resources [00000092 - 00000092] Motherboard resources [000000A0 - 000000 B1] Programmable interrupt controller (8259 slave) [000000B2 - 000000B3] Power management [000000B4 - 000000 BD]...
-
Page 18: System Memory Map
ISIS user manual System memory map System memory segment Description [000A0000 - 000BFFFF] Intel Poulsbo Graphics Controller Function 0 [000C0000 - 000DFFFF] Expansion area [000E0000 - 000EFFFF] Extended BIOS (LPC) [000F0000 - 000FFFFF] BIOS (LPC) [3FC00000 - 3FFFFFFF] PCI bus [40000000 - FEBFFFFF] PCI bus [40000000 - 7FFFFFFF]... -
Page 19: Interrupts
System resources Interrupts Interrupt source System timer PS/2 keyboard controller COM2* COM1* COM3* System CMOS/real time clock ACPI subsystem interrupt* PS/2 compatible mouse* IDE controller Intel Poulsbo Family PCI Express Root Port 1 - 8110 Intel 82551IT PCI Ethernet controller Intel Poulsbo Family USB Universal Host Controller - 8114 Intel Poulsbo Family USB Universal Host Controller - 8115 Intel Poulsbo Family USB Universal Host Controller –... -
Page 20: Hardware Specification
ISIS user manual Hardware specification Block diagram The following block diagram shows the implementation of the ISIS PC/104-Plus SBC: 2 x USB2.0 Host 2 x USB2.0 1x PCIe 1x PCIe MiniCard USB Hub USB2513i Core processor/chipset module The ISIS is based on the Intel Atom Z5xx series processor and US15W System Controller Hub (SCH). -
Page 21: Expansion Buses
Hardware specification Intel Atom processor is available in the following frequency SKU’s: Product Temperature Name Frequency range Package Chipset Pairing Z530 1.6GHz 2.2W 0C to +70C BGA-441 US15W (2.3W) 13x14mm BGA-1249 Z510 1.1GHz 0C to +70C BGA-441 22x22mm 13x14mm Z530P 1.6GHz 2.2W 0C to +70C... -
Page 22: Pci Express Mini Card Socket
ISIS user manual PC/104 bus interface PC/104 bus interface (www.pc104.org) supports 16-bit ISA compatible peripherals. Standard 64+40 way 0.1" stack-through connectors are used. See page 36 for connector pin details. If you are using a PC/104 card that requires +5V, this is automatically supplied via the PC/104 header. -
Page 23: Sdio/Mmc Socket
Hardware specification SDIO/MMC socket An SDIO bus socket is provided on the ISIS. The US15W SCH contains three SDIO/MMC ports. Ports 0 and 2 are 8-bits wide, while Port 1 is 4 bits wide. Port 1 is connected directly to the SDIO socket on the ISIS.The SDIO/MMC controller supports MMC4.0 and SDIO1.1 specifications. -
Page 24: Audio Support
20-pin header (J14), and an external adaptor board with the HD audio CODEC is required. A breakout board (ISIS-HDA) that contains HD audio codec (Analogue Devices AD1986A) is available from Eurotech, contact the sales team for details. -
Page 25: Usb Support
Ethernet). See page 46, for connector details. An external adaptor board with magnetics is required for operation of the Ethernet interface. An ACS-9095-05 adaptor is available from Eurotech. For more details, see Appendix B – ISIS cable kit, page 50. -
Page 26: Ide Support
ISIS user manual IDE support The US15W SCH parallel ATA/IDE interface is routed from the CPU module interface to a 44-pin header (J5) on the ISIS board. The US15W SCH’s PATA interface supports only the primary channel, with one master and one slave device. -
Page 27: Serial Ports
Hardware specification Serial ports The SMSC SCH3114 SuperIO provides four fully functional NS16C550 compatible serial ports on the ISIS board. It supports up to 115KBaud data rates and 16-Byte Send/Receive FIFO’s. RS-485 Auto Direction flow control mode is also supported. Serial port 1 is made available as a full RS-232 interface supporting all modem control lines, with a factory build option for TTL level signalling. -
Page 28: Gpio
ISIS user manual GPIO Eight general purpose IO’s are provided via a 12-way header (J15), these are individually configurable as inputs or outputs. GPIO1 and GPIO2 are 3.3V CMOS signals, derived from CPU module’s CPLD. The other six GPIO’s are derived from GPIO pins of a SuperIO device SCH3114. -
Page 29: Power Requirements
Hardware specification Power requirements The ISIS operates from +5V (+/-5%) power input. All other supply rails are generated on- board. A +12V supply connection is provided through J9, however the ISIS does not use this. The +12V and –12V rails are routed to PC/104-Plus and PC/104 connectors and can be used by other devices or modules that are stacked onto the ISIS module. -
Page 30: Mechanical
ISIS user manual Mechanical The ISIS is based on PC/104-Plus form factor standard. The CPU module is mounted via a 220-pin stacking interface connector to the ISIS board. An 8mm stacking height is used in order to accommodate PCI Express Mini Card heights of up to 5mm. - Page 31 Hardware specification Top and side view module ISIS Baseboard Heat spreader Top view (heat spreader not fitted) ISIS Baseboard module Issue E...
-
Page 32: Connectors, Jumpers And Leds
ISIS user manual Connectors, jumpers and LEDs The ISIS has the following connectors: Connector Function Connector details in section ISA Bus J1, J2 and J3 - Buses for PC/104-Plus connectivity, page ISA Bus J1, J2 and J3 - Buses for PC/104-Plus connectivity, page PCI Bus J1, J2 and J3 - Buses for PC/104-Plus... - Page 33 Connectors, jumpers and LEDs The ISIS has the following jumpers: Jumper Function Jumper details in section PATA Flash master/slave. JP2 - PATA Flash master/slave, page Default: closed (master) Supercap enable JP3 - On-board supercap selection, page Default: open (disable) PC/104-Plus signalling JP4 - PC/104-Plus signalling selection, Default: 1-2 (+5V)
-
Page 34: Top View
ISIS user manual Top view Issue E... -
Page 35: Bottom View
Connectors, jumpers and LEDs Bottom view The connectors on the following pages are shown in the same orientation as the diagrams above, unless otherwise stated. Issue E... -
Page 36: Connectors
ISIS user manual Connectors J1, J2 and J3 - Buses for PC/104-Plus connectivity Connector J1: Astron 25-1201-232-2G-R, 64-way, 2.54mm (0.1") x 2.54mm (0.1") stackthrough PC/104 compatible connector (Row A and B). Connector J2: Astron 25-1201-220-2G-R, 40-way, 2.54mm (0.1") x 2.54mm (0.1") stackthrough PC/104 compatible connector (Row C and D). - Page 37 Connectors, jumpers and LEDs Connector J3: Samtec ESQT-130-02-MQ-368, 120-way, 2mm (.0787") stackthrough PC/104-Plus compatible socket. Row A Row B Row C Row D RSVD C/BE0# AD11 AD10 M66EN AD14 AD13 AD12 +3.3V C/BE1# AD15 +3.3V SERR# SB0# PERR# +3.3V SDONE STOP# +3.3V LOCK#...
- Page 38 ISIS user manual J4 - Multifunction and VGA connector Connector : FCI Minitek 98464-G61-18ULF, 18-way, 2mm (.0787"), shrouded header. Mating socket : FCI Minitek 90311-018LF. Signal name Signal name KBDATA KBCLK MSDATA MSCLK BAT_IN PC_BEEP PB_RST# MON_HSYNC MON_VSYNC MON_RED MON_GREEN MON_SCL MON_SDA MON_BLUE...
- Page 39 Connectors, jumpers and LEDs J5 - IDE connector Connector : OUPIIN 2111-2X22-G-R, 44-way, 2mm (.0787"), header. Mating socket : FCI Minitek 89947-144LF 44-way (22x2), 2mm (.0787") IDC receptacle. Signal name Signal name RST# DD10 DD11 DD12 DD13 DD14 DD15 KEY20 DDREQ DIOW# DIOR#...
- Page 40 ISIS user manual J6 - 24-bit LVDS video Connector : JST FI-W21P-HFE, 21-way 1.25mm (0.05") header. Mating socket : JST FI-WE21S. Signal name Signal name +3.3V +3.3V LA_DATA0 LA_DATA0+ LA_DATA1- LA_DATA1+ LA_DATA2- LA_DATA2+ LA_CLK- LA_CLK+ LA_DATA3- LA_DATA3+ LVDS_MSEL N.C. Mode Select pin on some LVDS panels J7 - USB 2.0 (ports 2 and 3) Connector : JST S8B-PH-K-S, 8-way, 2mm (.0787"), shrouded header.
- Page 41 Connectors, jumpers and LEDs J8 - PCI Express Mini Card Connector : MOLEX 67910-0001, 52-way, 0.80mm (.310") PCI Express Mini Card connector. Signal name Signal name N.C. +3.3V N.C. N.C. +1.5V CLKREQ# UIM_PWR UIM_DATA REFCLK- UIM_CLK REFCLK+ UIM_RST# UIM_VPP N.C. N.C.
- Page 42 ISIS user manual J9 - Auxiliary power connector J9 is an auxiliary power connector and can be used to power the module as an alternative to the PC/104-Plus bus. Connector : SAMTEC 2TSW-106-08-G-D-RA, 12-way, 2.54mm (0.1"), header. Mating connector FCI 65043-031LF - 2.54mm receptacle housing. Crimp FCI 47750-000LF (22AWG wire).
- Page 43 Connectors, jumpers and LEDs J11 - SIM card Connector : AVX 00-9162-006-206-175, 6-way SIM card connector. Signal name UIM_PWR UIM_RST# UIM_CLK UIM_VPP UIM_DATA J12 - SD/SDIO/MMC Connector : MOLEX 67840-8001, 2.5mm (.098") SDIO memory card connector. Signal name SD1_DATA3 SD1_CMD +3.3V SD1_CLK SD1_DATA0...
- Page 44 ISIS user manual J14 - USB 2.0 (ports 6A and 6B) and HD audio Connector : FCI Minitek 98464-G61-20ULF, 20-way 2mm (.0787") shrouded header. Mating socket : FCI Minitek 90311-020LF. Signal name Signal name HDA_SPKR HDA_SDI1 HDA_SDO CDC_EN# HDA_SDI0 HDA_CLK HDA_RST# HDA_SYNC N.C.
- Page 45 Connectors, jumpers and LEDs J16 - USB 2.0 (ports 0, 1, 4, 5) Connector : FCI Minitek 98464-G61-16ULF, 16-way 2mm (.0787") shrouded header. Mating socket : FCI Minitek 90311-016LF. Signal name Signal name +V5_USB45 USB_D5- USB_D5+ +V5_USB45 USB_D4- USB_D4+ +V5_USB01 USB_D1- USB_D1+ +V5_USB01...
- Page 46 ISIS user manual J20 - 10/100 Ethernet Connector : JST S8B-PH-K-S, 8-way, 2mm (.0787"), shrouded header. Mating socket : JST PHR-8. Signal name LINK LED ACTIVITY LED +3.3V 100 series resistors included J22 - Backlight inverter control Connector : MOLEX 53047-0710, 7-way 1.25mm (.049"), shrouded header. Mating socket : MOLEX 51021-0700.
-
Page 47: Jumpers
Connectors, jumpers and LEDs Jumpers There are three jumpers on the ISIS; the use of each one is explained below. JP2 - PATA Flash master/slave JP2 pinout table: Signal name TB_CSEL# JP2 function table: Position Function Open PATA Flash is slave Closed (default) PATA Flash is master JP3 - On-board supercap selection... -
Page 48: Leds
ISIS user manual JP4 - PC/104-Plus signalling selection JP4 pinout table: Signal name +3.3V +VIO_PCI +3.3V JP4 function table: Position Function 1-2 (Default) 5V PC/104-Plus signalling 3.3V PC/104-Plus signalling Check your PC104-Plus peripheral module’s manual for correct VIO voltage. LEDs D6 –... -
Page 49: Appendix A - Isis Breakout Board
Appendix A – ISIS Breakout board Appendix A – ISIS Breakout board The ISIS-Breakout board is available for use with the ISIS. The ISIS-Breakout board supports the following: Power supply. Coin cell battery. PS/2 mouse and keyboard. ... -
Page 50: Appendix B - Isis Cable Kit
One multifunction adapter board with connecting cable. Dual USB type A The ACS-9092 is an adapter board that has been developed by Eurotech to simplify the interfacing of USB peripherals with Eurotech CPU modules. For more details about this board, see www.eurotech.com/DLA/AN/Td0002.pdf. -
Page 51: Cables
Appendix B – ISIS cable kit Audio The ISIS-HDA is an adapter board that has been developed by Eurotech to simplify the interfacing of Audio peripherals with the ISIS. The ISIS-HDA board contains the HD audio codec Analogue Devices AD1986A and supports standard line in, line out and microphone functionality or alternatively 5.1 surround sound on three board-mounted... - Page 52 The power cable 7020000011L provides unterminated colour coded wires allowing easy connection of the ISIS to the power supply. For more details about this cable, see www.eurotech.com/DLA/AN/Td0025.pdf Serial The serial cable 7000000074L provides two DB9-M connectors for interfacing with standard RS232 cables.
- Page 53 Appendix B – ISIS cable kit LVDS The LVDS cable (2042-53684-000-000 for ISIS v1i2, 2042-54022-000-000 for ISIS v1i3) allows for a straight connection of the ISIS to the 20-way connector of a NEC LVDS flat panel display (NL8060BC21-02). Cable Wire colour 21w double socket 20w single socket Pair...
- Page 54 ISIS user manual Backlight inverter The Backlight inverter cable (2042-53685-000-000) allows for a straight connection of the ISIS to the 8way connector of a +5V NEC backlight inverter. You can either use the existing inverter cable’s end socket or replace it to accommodate the cable for your own inverter.
-
Page 55: Appendix C - Ethernet Adaptor Schematic
Appendix C – Ethernet adaptor schematic Appendix C – Ethernet adaptor schematic This schematic, with the use of symmetrical RJ-45 Magjack (Xmultiple XRJG-01A-1-D12-110) enables the Auto-MDIX capability of the Intel 82551IT Ethernet controller. XRJG-01A-1-D12-110 ETHERNET ADAPTOR FOR ISIS ETH_TX+ RJ-1 RJ-4 RJ-5 ETH_TX-... -
Page 56: Appendix D - Reference Information
ISIS user manual Appendix D – Reference information Product information Product notices, updated drivers, support material: www.eurotech.com PCI special interest group PCI Bus specification and list of manufacturers: www.pcisig.org USB information Universal Serial Bus (USB) specification and product information: www.usb.org... -
Page 57: Appendix E - Rohs Compliance
July 2006. The ISIS board shall be designed using RoHS compliant components, and manufactured to comply with the RoHS Directive. Eurotech has based its material content knowledge on a combination of information provided by third parties and auditing our suppliers and sub-contractor’s operational activities and arrangements. This information is archived within the associated Technical Construction File. - Page 58 ISIS user manual Issue E...
-
