Pin
Side B
27
AD23
28
Ground
29
AD21
30
AD19
31
+3.3V
Slot
IDSEL
0
AD27
1
AD29
2
AD31
J14 – System control interface
10-way, 2.54mm (0.1") x 2.54mm (0.1") dual row header.
Mating connector: Harwin M20-1070500
Mating connector crimps: Harwin M20-1180022
Pin
Signal name
1
Tamper
3
Power Button
5
System Reset
7
+5V
9
PC speaker
Issue G
Side A
Pin
+3.3V
58
AD22
59
AD20
60
Ground
61
AD18
62
GNT/RQT
1
3
4 (JP1 jumper selected)
Pin
Signal name
2
Ground
4
Ground
6
Ground
8
HDD LED
10
Ground
Jumpers and connectors
Side B
Side A
AD01
AD00
+5V(I/O)
+5V(I/O)
/ACK64
/REQ64
+5V
+5V
+5V
+5V
