Eurotech Apollo User Manual page 27

APOLLO V1Ix: CMOS reset jumper
Used to clear the contents of the battery backed CMOS memory.
Please note:
•
•
•
CMOS
APOLLO V1Ix: TPM functionality jumper
This position is used with the APOLLO TPM to provide future functionality.
Issue G
Because CMOS values are backed up in an onboard EEPROM, clearing the
CMOS results in the CMOS values being reloaded from the EEPROM.
To restore the CMOS to factory default settings the USR1 jumper should be
used.
Changes to this jumper setting must only be made with board power
completely removed. To do this you must remove the power cable.
Description
Reset CMOS memory.
CMOS unchanged.
Jumpers and connectors
Default setting:
27
