Eurotech Apollo User Manual page 43

Pin Signal name
29 Ground
31 USB overcurrent
33 DVO_REF
35 /RESET
37 Ground
39 ADDID7
41 ADDID6
43 ADDID5
45 ADDID4
47 ADDID3
49 ADDID2
51 ADDID1
53 ADDID0
55 DVODETECT
57 DVOCFLDSTL
59 DVOBCINTR#
61 DVOBCCLKINT
63 Ground
65 +1.5V
67 +1.5V
69 +1.5V
71 +1.5V
73 MI2CDATA
75 MI2CCLK
77 MDVIDATA
79 MDVICLK
Issue G
Jumpers and connectors
Pin Signal name
30 DVOBCLK#
32 DVOBCLK
34 DVOBHSYNC
36 DVOBVSYNC
38 DVOBBLANK#
40 DVOBFLDSTL
42 Ground
44 DVOCD11
46 DVOCD10
48 DVOCD9
50 DVOCD8
52 DVOCD7
54 DVOCD6
56 DVOCD5
58 DVOCD4
60 DVOCD3
62 DVOCD2
64 DVOCD1
66 DVOCD0
68 Ground
70 DVOCCLK#
72 DVOCCLK
74 DVOCHSYNC
76 DVOCVSYNC
78 DVOCBLANK#
80 Ground
43
