Connectors

There are 34 connectors on the APOLLO that let you connect external devices such as
keyboards, floppy disk drives, hard disk drives, printers etc.
Connector
J1
J2
J3
J4A
J4B, J4C
J5A
J5B
J6A
J6B
J6C
J7A
J7B, J7C
J8
J9
J10
J11
J12
J13
J14
J15
J16
J17
Issue G
Function
Audio Line Out.
Audio Line In.
Audio Mic In.
IEEE1394 port 0.
USB ports 1 to 2.
Primary LAN.
Secondary LAN.
VGA connector.
Keyboard.
Mouse.
Parallel port (LPT1).
Serial ports 1 to 2.
S/PDIF output.
CD audio input.
System fan.
CPU fan.
ATX power connector.
PCI slot.
System control interface.
LCD backlight interface.
Video option and USB ports 5/6
connector.
LVDS display interface.
Jumpers and connectors
See ...
Page 32.
Page 32.
Page 32.
Page 34.
Page 34.
Page 35.
Page 35.
Page 36.
Page 36.
Page 36.
Page 37.
Page 38.
Page 38.
Page 38.
Page 39.
Page 39.
Page 39.
Page 40.
Page 41.
Page 42.
Page 42.
Page 44.
continued...
