APOLLO user manual
J13 – PCI connector
32-bit card edge connector. Three grant/request lines routed.
Connector: 120-way PCI card edge connector (5V 32-bit 33MHz PCI socket).
Pin Side B
1 -12V
2 TCK (GND)
3 Ground
4 No Connect
5 +5V
6 +5V
7 /INTF
8 /INTH
9 No Connect
10 / REQ3
11 No Connect
12 Ground
13 Ground
14 No Connect
15 Ground
16 CLK
17 Ground
18 /REQ1
19 +5V(I/O)
20 AD31
21 AD29
22 Ground
23 AD27
24 AD25
25 +3.3V
26 /CBE3
40
Side A Pin
/TRST 32
+12V 33
TMS (+5V) 34
TDI (+5V) 35
+5V 36
/INTE 37
/INTG 38
+5V 39
/REQ4 40
+5V(I/O) 41
/GNT3 42
Ground 43
Ground 44
VAUX (/GNT4) 45
/RST 46
+5V(I/O) 47
/GNT1 48
Ground 49
/PME 50
AD30 51
+3.3V 52
AD28 53
AD26 54
Ground 55
AD24 56
IDSEL (AD27) 57
Side B Side A
AD17 AD16
/CBE2 +3.3V
Ground /FRAME
/IRDY Ground
+3.3V /TRDY
/DEVSEL Ground
Ground /STOP
/LOCK +3.3V
/PERR SMB CLK
+3.3V SMB DATA
/SERR Ground
+3.3V PAR
/CBE1 AD15
AD14 +3.3V
Ground AD13
AD12 AD11
AD10 Ground
Ground AD09
Key Key
Key Key
AD08 /CBE0
AD07 +3.3V
+3.3V AD06
AD05 AD04
AD03 Ground
Ground AD02
continued...
