Appendix A – Specification
CPU
Cache
Memory
Video
Audio
Bus support
Issue G
The APOLLO supports:
• Intel Pentium M 478-pin μFCPGA package 90nm and
130nm processors with 400MHz FSB.
• Intel Celeron M 478-pin μFCPGA package 90nm and
130nm processors with 400MHz FSB.
• Intel Ultra Low Voltage Pentium M 479-pin μFCBGA
package with 400MHz FSB.
The APOLLO Celeron M 600MHz variant has a non-
interchangeable board mounted 600MHz Celeron M
processor.
Pentium M 130nm, 1MB L2 CPU Integrated
Pentium M 90nm, 2MB L2 CPU Integrated
Celeron M 130nm, 512KB L2 CPU Integrated
Celeron M 90nm, 1MB L2 CPU Integrated
One unbuffered 2.5V DDR SDRAM 184-pin DIMM socket
to support 128MB, 256MB, 512MB and 1024MB modules.
Supports:
•
PC1600 (200MHz) DDR SDRAM.
•
PC2100 (266MHz) DDR SDRAM.
•
PC2700 (333MHz) DDR SDRAM.
ECC and non-ECC memory is supported by the APOLLO.
Intel Extreme Graphics (chipset integrated).
VGA CRT interface: 2048x1536, 75Hz.
LVDS interface (dual channel): 1600x1200, 60Hz.
An option board interface provides a two channel DVO
interface to support:
•
Dual channel TMDS (DVI).
•
Dual channel LVDS.
•
TV out support.
Dual video operation allows for two independent video
displays.
5.1 surround sound AC-97 audio CODEC with variable
sampling rate and 3D stereo expansion for simulated
surround sound. A header for a speaker is included on the
board for PC BEEP functionality.
32-bit 33MHz PCI connector rev 2.2 (3 grant/request
pairs). Support for 3 PCI cards via a PCI riser card.
