LED indicators
Two new LEDs have been added to the APOLLO V2Ix board, these are used for a visual
indication of the board status:
LED
STANDBY
POWER LED
BOOT LED
Issue G
Colour and position
Purpose
Orange, situated
Provides a visual indication to the user when 5V
next to the PCI
standby power is present on the board to
connector.
prevent PCI cards being inserted while power is
applied.
Red, situated next
Shows the boot status of the board.
to IEEE1394
Flashing signifies that the BIOS is booting or the
connector (J19).
BIOS setup screen is active.
The BOOT LED is cleared at the time the BIOS
hands over control to the operating system. This
can be used to help determine BIOS/OS related
boot issues.
LED indicators
21
