2 Parameter Description
2.9.3 8-1* Ctrl. Word Settings
Parameters for configuring the option control word profile.
8-10 Control Profile
2
Option:
[0] * FC profile
[1] PROFIdrive profile
[5] ODVA
[7] CANopen DSP 402
8-13 Configurable Status Word STW
Option:
[0] No function
[1] * Profile Default
[2] Alarm 68 Only
[3] Trip excl Alarm 68
[16] T37 DI status
2.9.4 8-3* FC Port Settings
Parameters for configuring the FC Port.
8-30 Protocol
Option:
[0] * FC
[1] FC MC
[2] Modbus RTU
[9] FC option
8-31 Address
Range:
1. N/A* [1. - 126. N/A]
98
Function:
Select the interpretation of the control and status words corresponding to the installed fieldbus.
Only the selections valid for the fieldbus installed in slot A will be visible in the LCP display.
Function:
This parameter enables configuration of bits 12 – 15 in the status word.
Function corresponds to the profile default selected in par.8-10
Only set in case of an Alarm 68.
Set in case of a trip, except if the trip is executed by an Alarm 68.
The bit indicates the status of terminal 37.
"0" indicates T37 is low (safe stop)
"1" indicates T37 is high (normal)
Function:
Protocol selection for the integrated FC (standard) Port (RS485) on the control card.
Communication according to the FC Protocol as described in
Same as FC [0] but to be used when downloading SW to the frequency converter or uploading dll
file (covering information regarding parameters available in the frequency converter and their inter-
dependencies) to Motion Control Tool MCT10.
Communication according to the Modbus RTU protocol.
Function:
Enter the address for the FC (standard) port.
Valid range: 1 - 126.
®
MG.20.O4.02 - VLT is a registered Danfoss trademark
®
VLT AQUA Drive Programming Guide
Control Profile .
RS-485 Installation and Set-up
.
