[100] Output freq. 0-100
[101] Reference Min-Max
[102] Feedback +-200%
[103] Motor cur. 0-Imax
[104] Torque 0-Tlim
[105] Torque 0-Tnom
[106] Power 0-Pnom
[107] Speed 0-HighLim
[113] Ext. Closed Loop 1
[114] Ext. Closed Loop 2
[115] Ext. Closed Loop 3
[139] Bus ctrl.
[141] Bus ctrl t.o.
26-51 Terminal X42/9 Min. Scale
Range:
0.00 %* [0.00 - 200.00 %]
Terminal 42 Output Min Scale
See principle graph for par.6-51
26-52 Terminal X42/9 Max. Scale
Range:
100.00 %* [0.00 - 200.00 %]
See principle graph for par.6-52 Terminal 42 Output Max Scale
26-53 Terminal X42/9 Bus Control
Range:
0.00 %* [0.00 - 100.00 %]
26-54 Terminal X42/9 Timeout Preset
Range:
0.00 %* [0.00 - 100.00 %]
26-60 Terminal X42/11 Output
Option:
[0] * No operation
: 0 - 100%, (0-20 mA)
: 0 - 100%, (0-20 mA)
: 0 - 100%, (0-20 mA)
: 0 - 100%, (0-20 mA)
: 0 - 100%, (0-20 mA)
Function:
Scale the minimum output of the selected analog signal at terminal X42/9, as a percentage of the
maximum signal level. E.g. if a 0 V is desired at 25% of the maximum output value. Then programme
25%. Scaling values up to 100% can never be higher than the corresponding setting in par.
Terminal X42/9 Max. Scale
26-52 .
.
Function:
Scale the maximum output of the selected analog signal at terminal X42/9. Set the value to the
maximum value of the voltage signal output. Scale the output to give a voltage lower than 10V at
full scale; or 10V at an output below 100% of the maximum signal value. If 10V is the desired output
current at a value between 0-100% of the full-scale output, programme the percentage value in the
parameter, i.e. 50% = 10V. If a voltage between 0 and 10V is desired at maximum output, calculate
the percentage as follows:
( )
V
10
x
100 %
desired maximum voltage
i.e.
10 V
5 V : x 100 % = 200 %
5 V
.
Function:
Holds the level of terminal X42/9 if controlled by bus.
Function:
Holds the preset level of terminal X42/9.
In case of a bus timeout and a timeout function is selected in par.26-60
the output will preset to this level.
Function:
Set the function of terminal X42/11.
®
