2 Parameter Description
2.15 Main Menu - Data Readouts - Group 16
2.15.1 16-** Data Readouts
2
Parameter group for data read-outs, e.g. actual references, voltages, control, alarm, warning and status words.
2.15.2 16-0* General Status
Parameters for reading the general status, e.g. the calculated reference, the active control word, status.
16-00 Control Word
Range:
0 N/A*
[0 - 65535 N/A]
16-01 Reference [Unit]
Range:
0.000 Ref-
[-999999.000 - 999999.000 Refer-
erenceFeed-
enceFeedbackUnit]
backUnit*
16-02 Reference [%]
Range:
0.0 %*
[-200.0 - 200.0 %]
16-03 Status Word
Range:
0 N/A*
[0 - 65535 N/A]
16-05 Main Actual Value [%]
Range:
0.00%*
[-100.00% - 100.00%]
16-09 Custom Readout
Range:
0.00
Cus-
[-999999.99 - 999999.99 Custom-
tomReadou-
ReadoutUnit]
tUnit*
2.15.3 16-1* Motor Status
Parameters for reading the motor status values.
16-10 Power [kW]
Range:
0.00 kW*
[0.00 - 10000.00 kW]
150
Function:
View the Control word sent from the frequency converter via the serial communication port in hex
code.
Function:
View the present reference value applied on impulse or analog basis in the unit resulting from the
configuration selected in par.1-00
Configuration Mode
Function:
View the total reference. The total reference is the sum of digital, analog, preset, bus, and freeze
references, plus catch-up and slow-down.
Function:
View the Status word sent from the frequency converter via the serial communication port in hex
code.
Function:
View the two-byte word sent with the Status word to the bus Master reporting the Main Actual Value.
Please refer to the Profibus Operating Instructions MG.33.CX.YY for a detailed description.
Function:
View the user-defined readouts as defined in par.0-30
Readout Min Value
Custom Readout Max Value
and par.0-32
Function:
View the motor power in kW. The value shown is calculated on the basis of the actual motor voltage
and motor current. The value is filtered, and therefore approx. 30 ms may pass from when an input
value changes to when the data read-out values change.
®
MG.20.O4.02 - VLT
is a registered Danfoss trademark
®
VLT
AQUA Drive Programming Guide
(Hz, Nm or RPM).
Custom Readout Unit
, par.0-31
.
Custom
