Danfoss VLT AQUA FC 200 Series Programming Manual page 159

®
VLT AQUA Drive Programming Guide
18-30 Analog Input X42/1
Range:
0.000 N/A* [-20.000 - 20.000 N/A]
18-31 Analog Input X42/3
Range:
0.000 N/A* [-20.000 - 20.000 N/A]
18-32 Analog Input X42/5
Range:
0.000 N/A* [-20.000 - 20.000 N/A]
18-33 Analog Out X42/7 [V]
Range:
0.000 N/A* [0.000 - 30.000 N/A]
18-34 Analog Out X42/9 [V]
Range:
0.000 N/A* [0.000 - 30.000 N/A]
18-35 Analog Out X42/11 [V]
Range:
0.000 N/A* [0.000 - 30.000 N/A]
Function:
Read out of the value of the signal applied to terminal X42/1 on the Analog I/O Card.
The units of the value shown in the LCP will correspond to the mode selected in par.26-00
X42/1 Mode
.
Function:
Read out of the value of the signal applied to terminal X42/3 on the Analog I/O Card.
The units of the value shown in the LCP will correspond to the mode selected in par.26-01
X42/3 Mode
.
Function:
Read out of the value of the signal applied to terminal X42/5 on the Analog I/O Card.
The units of the value shown in the LCP will correspond to the mode selected in par.26-02
X42/5 Mode
.
Function:
Read out of the value of the signal applied to terminal X42/7 on the Analog I/O Card.
The value shown reflects the selection in par.26-40
Function:
Read out of the value of the signal applied to terminal X42/9 on the Analog I/O Card.
The value shown reflects the selection in par.26-50
Function:
Read out of the value of the signal applied to terminal X42/11 on the Analog I/O Card.
The value shown reflects the selection in par.26-60
®
MG.20.O4.02 - VLT is a registered Danfoss trademark
2 Parameter Description
Terminal X42/7 Output
.
Terminal X42/9 Output .
Terminal X42/11 Output .
Terminal
2
Terminal
Terminal
159
