VLT AQUA Drive Programming Guide
13-40 Logic Rule Boolean 1
Array [6]
Option:
[0] * False
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
Function:
Enters the fixed value of FALSE in the logic rule.
Enters the fixed value TRUE in the logic rule.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
Use the result of comparator 0 in the logic rule.
Use the result of comparator 1 in the logic rule.
Use the result of comparator 2 in the logic rule.
Use the result of comparator 3 in the logic rule.
Use the result of logic rule 0 in the logic rule.
Use the result of logic rule 1 in the logic rule.
Use the result of logic rule 2 in the logic rule.
Use the result of logic rule 3 in the logic rule.
Use the result of timer 0 in the logic rule.
Use the result of timer 1 in the logic rule.
Use the result of timer 2 in the logic rule.
Use the value of DI18 in the logic rule (High = TRUE).
Use the value of DI19 in the logic rule (High = TRUE).
Use the value of DI27 in the logic rule (High = TRUE).
®
MG.20.O4.02 - VLT is a registered Danfoss trademark
2 Parameter Description
