2 Parameter Description
[1667] Pulse Input #29 [Hz]
[1668] Pulse Input #33 [Hz]
[1669] Pulse Output #27 [Hz]
[1670] Pulse Output #29 [Hz]
2
[1671] Relay Output [bin]
[1672] Counter A
[1673] Counter B
[1675] Analog In X30/11
[1676] Analog In X30/12
[1677] Analog Out X30/8 [mA]
[1684] Comm. Option STW
[1685] FC Port CTW 1
[1690] Alarm Word
[1691] Alarm Word 2
[1692] Warning Word
[1693] Warning Word 2
[1694] Ext. Status Word
[1695] Ext. Status Word 2
[1696] Maintenance Word
[1830] Analog Input X42/1
[1831] Analog Input X42/3
[1832] Analog Input X42/5
[1833] Analog Out X42/7 [V]
[1834] Analog Out X42/9 [V]
[1835] Analog Out X42/11 [V]
9-18 Node Address
Range:
126 N/A* [0 - 126. N/A]
9-22 Telegram Selection
Option:
[1] Standard telegram 1
[101] PPO 1
[102] PPO 2
[103] PPO 3
[104] PPO 4
[105] PPO 5
[106] PPO 6
[107] PPO 7
[108] * PPO 8
[200] Custom telegram 1
106
Function:
Enter the station address in this parameter or alternatively in the hardware switch. In order to adjust
Node Address
the station address in par.9-18
all switches set to 'on'). Otherwise this parameter will display the actual setting of the switch.
Function:
Select a standard Profibus telegram configuration for the frequency converter, as an alternative to
using the freely configurable telegrams in par.9-15
Configuration
.
®
MG.20.O4.02 - VLT is a registered Danfoss trademark
®
VLT AQUA Drive Programming Guide
, the hardware switch must be set to 126 or 127 (i.e.
PCD Write Configuration
and par.9-16
PCD Read
