Danfoss VLT AQUA FC 200 Series Programming Manual page 51

®
VLT AQUA Drive Programming Guide
3-11 Jog Speed [Hz]
Range:
10.0 Hz* [0.0 - par. 4-14 Hz]
3-13 Reference Site
Option:
[0] * Linked to Hand / Auto
[1] Remote
[2] Local
3-14 Preset Relative Reference
Range:
0.00 %* [-100.00 - 100.00 %]
3-15 Reference 1 Source
Option:
[0] No function
[1] * Analog input 53
Function:
The jog speed is a fixed output speed at which the frequency converter is running when the jog
function is activated.
Jog Ramp Time
See also par.3-80 .
Function:
Select which reference site to activate.
Use local reference when in Hand mode; or remote reference when in Auto mode.
Use remote reference in both Hand mode and Auto mode.
Use local reference in both Hand mode and Auto mode.
NB!
When set to Local [2], the frequency converter will start with this setting again
following a 'power down'.
Function:
The actual reference, X, is increased or decreased with the percentage Y, set in par.3-14
Relative Reference
. This results in the actual reference Z. Actual reference (X) is the sum of the
Reference 1 Source
inputs selected in par.3-15
3 Source Control Source
and par. 8-02
Function:
Select the reference input to be used for the first reference signal. par.3-15
par.3-16 Reference 2 Source and par.3-17
signals. The sum of these reference signals defines the actual reference.
This parameter cannot be adjusted while the motor is running.
®
MG.20.O4.02 - VLT is a registered Danfoss trademark
2 Parameter Description
Reference 2 Source
, par.3-16
.
Reference 3 Source define up to three different reference
2
Preset
Reference
, par.3-17
Reference 1 Source ,
51
