Danfoss VLT AQUA FC 200 Series Programming Manual page 154

2 Parameter Description
2
16-61 Terminal 53 Switch Setting
Option:
[0] * Current
[1] Voltage
[2] Pt 1000 [°C]
[3] Pt 1000 [°F]
[4] Ni 1000 [°C]
[5] Ni 1000 [°F]
16-62 Analog Input 53
Range:
0.000 N/A* [-20.000 - 20.000 N/A]
16-63 Terminal 54 Switch Setting
Option:
[0] * Current
[1] Voltage
[2] Pt 1000 [°C]
[3] Pt 1000 [°F]
[4] Ni 1000 [°C]
[5] Ni 1000 [°F]
16-64 Analog Input 54
Range:
0.000 N/A* [-20.000 - 20.000 N/A]
16-65 Analog Output 42 [mA]
Range:
0.000 N/A* [0.000 - 30.000 N/A]
16-66 Digital Output [bin]
Range:
0 N/A* [0 - 15 N/A]
154
Bit 0 Digital input term. 33
Bit 1 Digital input term. 32
Bit 2 Digital input term. 29
Bit 3 Digital input term. 27
Bit 4 Digital input term. 19
Bit 5 Digital input term. 18
Bit 6 Digital input term. 37
Bit 7 Digital input GP I/O term. X30/2
Bit 8 Digital input GP I/O term. X30/3
Bit 9 Digital input GP I/O term. X30/4
Bit 10-63 Reserved for future terminals
Function:
View the setting of input terminal 53. Current = 0; Voltage = 1.
Function:
View the actual value at input 53.
Function:
View the setting of input terminal 54. Current = 0; Voltage = 1.
Function:
View the actual value at input 54.
Function:
View the actual value at output 42 in mA. The value shown reflects the selection in par.6-50
42 Output
.
Function:
View the binary value of all digital outputs.
®
MG.20.O4.02 - VLT is a registered Danfoss trademark
®
VLT AQUA Drive Programming Guide
Terminal
