VLT AQUA Drive Programming Guide
2.8.7 6-5* Analog Output 1
Parameters for configuring the scaling and limits for analog output 1, i.e. Terminal 42. Analog outputs are current outputs: 0/4 – 20 mA. Common terminal
(terminal 39) is the same terminal and has the same electrical potential for analog common and digital common connection. Resolution on analog output
is 12 bit.
6-50 Terminal 42 Output
Option:
[0] * No operation
[100] Output freq. 0-100
[101] Reference Min-Max
[102] Feedback +-200%
[103] Motor cur. 0-Imax
[104] Torque 0-Tlim
[105] Torque 0-Tnom
[106] Power 0-Pnom
[107] Speed 0-HighLim
[113] Ext. Closed Loop 1
[114] Ext. Closed Loop 2
[115] Ext. Closed Loop 3
[130] Out frq 0-100 4-20mA
[131] Reference 4-20mA
[132] Feedback 4-20mA
[133] Motor cur. 4-20mA
[134] Torq.0-lim 4-20 mA
[135] Torq.0-nom 4-20mA
[136] Power 4-20mA
[137] Speed 4-20mA
[139] Bus ctrl.
[140] Bus ctrl. 4-20 mA
[141] Bus ctrl t.o.
[142] Bus ctrl t.o. 4-20mA
[143] Ext. CL 1 4-20mA
[144] Ext. CL 2 4-20mA
[145] Ext. CL 3 4-20mA
NB!
Values for setting the Minimum Reference is found in open loop par.3-02
Feedb.
- values for maximum reference for open loop is found in par.3-03
Feedb.
.
Function:
Select the function of Terminal 42 as an analog current output. A motor current of 20 mA corre-
sponds to I .
max
: 0 - 100 Hz, (0-20 mA)
: Minimum reference - Maximum reference, (0-20 mA)
: -200% to +200% of par. 20-14, (0-20 mA)
: 0 - Inverter Max. Current (par. 16-37), (0-20 mA)
: 0 - Torque limit (par. 4-16), (0-20 mA)
: 0 - Motor rated torque, (0-20 mA)
: 0 - Motor rated power, (0-20 mA)
: 0 - Speed High Limit (par. 4-13 and par. 4-14), (0-20 mA)
: 0 - 100%, (0-20 mA)
: 0 - 100%, (0-20 mA)
: 0 - 100%, (0-20 mA)
: 0 - 100 Hz
: Minimum Reference - Maximum Reference
: -200% to +200% of par. 20-14
: 0 - Inverter Max. Current (par.16-37
: 0 - Torque limit (par. 4-16)
: 0 - Motor rated torque
: 0 - Motor rated power
: 0 - Speed High Limit (par. 4-13 and par. 4-14)
: 0 - 100%, (0-20 mA)
: 0 - 100%
: 0 - 100%, (0-20 mA)
: 0 - 100%
: 0 - 100%
: 0 - 100%
: 0 - 100%
Minimum Reference
Maximum Reference
®
MG.20.O4.02 - VLT is a registered Danfoss trademark
2 Parameter Description
Inv. Max. Current
)
and for closed loop par. 20-13
and for closed loop par. 20-14
2
Minimum Reference/
Maximum Reference/
