RUGGEDCOM ROS
User Guide
Command
sshpubkey
sslkeygen
keytype
telnet
dest
tftp {
|
dest
|
fdest
}
trace
type
filename
version
xmodem { send | receive }
filename
Section 2.6.2
Tracing Events
The CLI trace command provides a means to trace the operation of various protocols supported by the device.
Trace provides detailed information, including STP packet decodes and MAC address displays.
NOTE
Tracing has been designed to provide detailed information to expert users. Note that all tracing is
disabled upon device startup.
To trace an event, do the following:
1.
Log in to the device as an admin user and access the CLI shell. For more information about accessing the CLI
shell, refer to
Section 2.6, "Using the Command Line Interface"
2.
Determine the protocols and associated options available by typing:
trace ?
If an option such as allon or alloff is required, determine which options are available for the desired
protocol by typing:
Tracing Events
Description
List, remove and update key entries in sshpub.keys file.
Generates a new SSL certificate in ssl.crt.
N
Optional and/or required parameters include:
• keytype is the type of key, either rsa or ecc
• N is the number of bits in length. For RSA keys, the allowable sizes are 1024, 2048 or
3072. For ECC keys, the allowable sizes are 192, 224, 256, 384, or 521.
Opens a telnet session. Press Ctrl-C to close the session.
Optional and/or required parameters include:
• dest is the server's IP address
Opens a TFTP session. Press Ctrl-C to close the session.
|
cmd
fsource
Optional and/or required parameters include:
• dest is the remote TFTP server's IP address
• cmd is either put (upload) or get (download)
• fsource is the source filename
• fdest is the destination filename
Starts event tracing. Run trace ? for more help.
Displays the contents of a text file.
Optional and/or required parameters include:
• filename is the name of the file to be read
Prints the software version.
Opens an XModem session.
Optional and/or required parameters include:
• send sends the file to the client.
• receive receives the file from the client.
• filename is the name of the file to be read.
.
Chapter 2
Using ROS
39
