SUPER DAVE MX2
THROTTLE SERVO ARM INSTALLA-
Install adjustable servo connector in the ser-
vo arm as same as picture below:
Loctite secure.
1 PCS.
Throttle

INSTALLING THE SWITCH.

Install the switch into the precut hole in the
side, in the fuselage.
Trim and cut.
10
TION.
Adjustable Servo
connector.
Servo arm
Rudder
Elevator
3/32'' Hole.
Instruction Manual.
Switch.

MOUNTING THE ENGINE .

1) Position the engine with the drive washer
(125mm) forward of the firewall as shown.
125 mm
Trim and cut.
Switch.
