Seagull Models SuperDave MX2 Assembly Manual page 24

SUPER DAVE MX2
Receiver
ATTACHMENT WING-FUSELAGE.
Attach the aluminium tube into fuselage.
Wing Tube.
Insert two wing panels as pictures below.
24
Battery.
1) It is critical that your airplane be bal-
anced correctly. Improper balance will
cause your plane to lose control and
crash. THE CENTER OF GRAVITY IS
LOCATED 110 MM BACK FROM THE
LEADING EDGE OF THE WING AT
THE WING ROOT.
2) Mount the wing to the fuselage. Using
a couple of pieces of masking tape, place
them on the top side of the wing 110 mm
back from the leading edge of the wing at
the wing root.
3) Turn the airplane upside down. Place
your fingers on the masking tape and
carefully lift the plane .
Instruction Manual.
Wing Bolt
4x20 mm
BALANCING.
