SUPER DAVE MX2
3) Attach the motor to the front of the elec-
tric motor box using four 4mm blind nut,
four M3x15mm hex head bolts to secure the
motor. Please see picture shown.
14
4mm
Nut M3
Instruction Manual.
4) Locate the plywood battery tray to the
fuselage. Tighten the screws using machine
screws M3x15mm to secure the tray in posi-
tion.
125mm
Balsa
Epoxy
5) Attach the speed control to the side of the
motor box using two-sided tape and tie
wraps. Connect the appropriate leads from
the speed control to the motor. Make sure
the leads will not interfere with the opera-
tion of the motor.
3x15 mm
Epoxy
