INSTALLING THE SWITCH.

Install the switch into the precut hole in the
side of the fuselage.
Switch.

INSTALLING THE AILERON SERVOS.

Servos.
Because the size of servos differ, you
may need to adjust the size of the precut open-
ing in the mount. The notch in the sides of
the mount allow the servo lead to pass through.
www.seagullmodels.com
Switch.
Small weight.
String.
Using a small weight (
) and string, feed the string through
works well
the wing as indicated.
Small weight.
Small weight.
Attach the string to the servo lead and
carefully thread it though the wing. Once you
have string the lead throught the wing, remove
the string so it can use for the other servo
lead. Tape the servo lead to the wing to prevent
it from falling back into the wing.
String.
Weighted fuel pick-up
String.
String.
Electric wire.
9
