Appendix A. Connector Pin Definitions
Table A-8. DSX-1 Connector Pinouts
Pin
Name
1
R
2
T
3
—
4
R1
5
T1
6-8
—
Table A-9. G.703 Connector Pinouts
Pin
Name
1
R
2
T
3
—
4
R1
5
T1
6-8
—
Table A-10. WAN-SHDSL Connector Pinouts
Pin
Name
1-3
—
4
T
5
R
6-8
—
Table A-11. WAN-ADSL Connector Pinouts
Pin
Name
1, 2
—
3
R
4
5, 6
—
64
Description
Transmit data toward the DTE–Ring
Transmit data toward the DTE–Tip
Unused
Receive data from the DTE–Ring 1
Receive data from the DTE–Tip 1
Unused
Description
Transmit data toward the DTE–Ring
Transmit data toward the DTE–Tip
Unused
Receive data from the DTE–Ring 1
Receive data from the DTE–Tip 1
Unused
Description
Unused
Transmit data toward the network–Tip
Transmit data toward the network–Ring
Unused
Unused
ADSL Ring
T
ADSL Tip
Unused
Copyright © 2007 ADTRAN, Inc.
NetVanta 1000/1000R Series Hardware Installation Guide
Description
61200500L1-34L
