1. INTRODUCTION
The NetVanta 1000 Series includes the NetVanta 1224, NetVanta 1224 PoE, NetVanta 1224ST,
NetVanta 1224ST PoE, NetVanta 1335, NetVanta 1335 PoE, NetVanta 1335 WiFi, NetVanta 1335 WiFi
PoE, and the NetVanta 1524ST. The NetVanta 1000R Series includes the NetVanta 1224R, NetVanta
1224R PoE, NetVanta 1224STR (AC), NetVanta 1224STR (DC), and NetVanta 1224STR PoE.
This hardware installation guide lists the NetVanta 1000 and 1000R Series units' specifications, describes
the physical characteristics of the units, introduces basic functionality, and provides installation
instructions. All NetVanta 1000 and 1000R Series units run the ADTRAN Operating System (AOS) and
are managed through an EIA-232

Power over Ethernet

The NetVanta 1000 and 1000R Series Power over Ethernet (PoE) devices provide the same basic functionality
as the NetVanta 1000 Series products. Power over Ethernet provides the ability to detect attached powered
devices (PD) and deliver 48 VDC to the PD via existing CAT5 cabling. The PoE devices are fully compliant
with the IEEE 802.3af power over Ethernet standard. By default, the PoE switches discover and provide power
to IEEE-compliant PDs.

Wireless Access

The NetVanta 1335 Wireless Fidelity (WiFi) Series provides a single access point for connection with IEEE
802.11a/b/g wireless networks. A dual radio design with two dual-band external antennas is used to support
concurrent 802.11a and 802.11b/g connections.

SFP Module Slots

The NetVanta 1224ST, NetVanta 1224STR PoE, NetVanta 1335, and NetVanta 1335 PoE support two SFP
slots; the NetVanta 1224STR, NetVanta 1335 WiFi, and NetVanta 1335 WiFi PoE have one; and the
NetVanta 1524ST has four. All accept a number of industry-standard SFP modules. The SFP modules provide
Gigabit Ethernet connectivity over fiber for high-speed uplinks or switch stacking. The following modules are
available for purchase (both of these modules require fiber optic cable with LC connectors):
• 1200480L1
• 1200481L1
In this document, the term "NetVanta" means all NetVanta 1000 and NetVanta 1000R Series
products. If a statement only applies to one particular unit, the text refers to the unit
individually. Additionally, unless otherwise specified, descriptions for a NetVanta 1000 or
1000R Series device also applies to the Power over Ethernet (PoE) and WiFi versions of
that device.
61200500L1-34L
CONSOLE port (DB-9) located on the rear panel.
1000BaseSX Multi-Mode SFP Module
1000BaseLX Single-Mode SFP Module
Copyright © 2007 ADTRAN, Inc. 15
