NetVanta 1000/1000R Series Hardware Installation Guide
NetVanta Serial DIM (P/N 1200886L1)
The NetVanta Serial DIM provides NetVanta products with the ability to interface with external devices (e.g.,
Code Division Multiple Access (CDMA) devices and wireless modems), allowing for dial backup access to the
public switched telephone network (PSTN). This DIM is a plug-on module that connects to the NIM. For
installation instructions, see Installing Dial Backup and Network Interface Modules on page 54.
An RJ-45 to DB-9 adapter cable (P/N 1200887L1) is required to connect to the external
modem.
Features and Specifications
Features
• 5-pin RS-232 interface vial host RJ-45 DBU connector
• Modem flow control support via CTS
• Communications with external model via AT commands
Compliance
• EMC - see Electromagnetic Compatibility (EMC) Table on page 6.
• IEC 60950
• EN 60950
• UL/CL 60950
• AS/NZS 60950
Environmental
• Operating Temperature: 0°C to 50°C
• Storage Temperature: -20°C to 70°C
• Relative Humidity: Up to 95 percent, noncondensing
Physical
• Dimensions: 2.3-inch W x 2.75-inch D
