NetVanta 1000/1000R Series Hardware Installation Guide
Installing Wireless Access Antennas (NetVanta 1335 WiFi and NetVanta 1335 WiFi
PoE only)
The NetVanta 1335 WiFi Series units ship with two dual-band RP-SMA detachable antennas. These must be
installed before operating the unit.
Step
1 Place either of the two antennas directly onto the antenna port labeled ANT 1 on the rear panel.
See Figure 19 on page 28 for port locations.
2 Twist the antenna onto the threads until it is secure.
3 Repeat step 2 with the second antenna, attaching it to the ANT 2 port.
Your NetVanta is now ready to be configured and connected to the network. For more information on
configuration for a specific application, refer to the quick configuration documents provided on the ADTRAN
OS System Documentation CD. For details on the command line interface, refer to the Command Reference
Guide (also included on your CD).
61200500L1-34L
Instructions for Installing Antennas
Action
Copyright © 2007 ADTRAN, Inc.
Unit Installation
59
