Physical Descriptions
Domestic shipments of the NetVanta 1224STR include the following items:
• NetVanta 1224STR base unit
• ADTRAN OS System Documentation CD
• A detachable power cable with a grounded, three-prong plug
• Quick Start Guide
• Warranty card
International shipments of the NetVanta 1224STR include the following items:
• NetVanta 1224STR base unit
• ADTRAN OS System Documentation CD
• All necessary power cords
• Quick Start Guide
• Warranty card
NetVanta 1224STR Front Panel Design
The NetVanta 1224STR and the NetVanta 1224STR PoE front panels are shown below. Table 1 on page 32
describes all of the LEDs, and Appendix A on page 61 shows the pinouts for the connectors.
NetVanta 1224STR Front Panel Features
10/100BaseT Ethernet Interfaces
The NetVanta 1224STRs contain 24 10/100BaseT Ethernet interfaces (RJ-45). These interfaces are
consecutively numbered 1 through 24, from left to right, with the numbers screened directly above
each port. Status LEDs for each of these interfaces are located directly over these numbers.
The NetVanta 1224STR PoE also has green and red PoE status LEDs located in the upper left and
upper right corners (respectively) of each Ethernet connector.
Gigabit Ethernet Interfaces/SFP Slots
The NetVanta 1224STR front panel contains one Gigabit Ethernet interface that provides one fixed
RJ-45 connector and one standard small form-factor pluggable (SFP) slots for connectivity over fiber.
(Use either the RJ-45 connectors or the SFP slots. The fiber slots have precedence.) This interfaces is
labeled G1 and the status LED is located to the left of RJ-45 port 1, above the
The NetVanta 1224STR PoE front panel contains two Gigabit Ethernet interfaces and two standard
small form-factor pluggable (SFP) slots. (Use either the RJ-45 connectors or the SFP slots. The fiber
slots have precedence.) These interfaces are labeled
the SFP slots.
24
NetVanta 1000/1000R Series Hardware Installation Guide
G1 and G2
Copyright © 2007 ADTRAN, Inc.
STAT LED.
and the status LEDs are located above
61200500L1-34L
