Physical Descriptions
NetVanta 1224ST
The NetVanta 1224ST and NetVanta 1224ST PoE are managed switches housed in a 1U-high rack-mountable
metal enclosure that includes a universal AC power supply. The front panel contains 24 10/100BaseT Ethernet
interfaces (RJ-45). The NetVanta 1224ST front panel contains two Gigabit Ethernet interfaces that provide two
fixed RJ-45 connectors and two standard small form-factor pluggable (SFP) slots for connectivity over fiber.
The NetVanta 1224ST PoE version provides the ability to detect attached powered devices (PDs) and deliver
48 VDC to the PDs via existing CAT5 cabling.
This section includes a list of features, a list of shipping contents, and a description of the unit's front and rear
panel designs. For additional information, refer to the following sections:
• Product Specifications on page 33
• Mounting Options on page 51
• Supplying Power to the Unit on page 53
For information on switch configuration for a specific application, refer to the quick configuration documents
provided on the ADTRAN OS System Documentation CD shipped with your base unit. For details on the
command line interface, refer to the Command Reference Guide (also included on your CD).
NetVanta 1224ST Shipping Contents
Each NetVanta 1224ST unit is shipped in its own cardboard shipping carton. Open each carton carefully, and
avoid deep penetration into the carton with sharp objects.
After unpacking the unit, inspect it for possible shipping damage. If the equipment has been damaged in transit,
immediately file a claim with the carrier and contact ADTRAN Customer Service (refer to the Repair and
Replacement section of the Support page on the ADTRAN website at http://www.adtran.com/support).
Domestic shipments of the NetVanta 1224ST include the following items:
• NetVanta 1224ST base unit
• ADTRAN OS System Documentation CD
• A detachable power cable with a grounded, three-prong plug
• Quick Start Guide
• Warranty card
International shipments of the NetVanta 1224ST include the following items:
• NetVanta 1224ST base unit
• ADTRAN OS System Documentation CD
• All necessary power cords
• Quick Start Guide
• Warranty card
NetVanta 1224ST Front Panel Design
The NetVanta 1224ST and the NetVanta 1224ST PoE front panels are shown below. Table 1 on page 32
describes all of these LEDs, and Appendix A on page 61 shows the pinouts for the connectors.
