ADTRAN NetVanta 1335 Specifications

Product Features

Multiservice Access
■
Router with integrated
Layer 3 PoE switch, and
802.11a/b/g Dual Radios
RapidRoute technology
™
■
for greater performance
Supports up to two T1s
■
worth of bandwidth
24-port Ethernet, Fast
■
Ethernet, or 802.3af
PoE functionality
Gigabit SFP/1000Base-T
■
Ethernet port(s) support
stacking capability
Stacking up to 16 switches
■
using single IP address
to manage
8.8 Gbps non-blocking
■
switching capacity
Link Aggregation, GVRP,
■
and LLDP
MAC-based port security
■
SIP ALG for NAT traversal
■
in VoIP applications
IPSec VPN for secure
■
corporate connectivity
across the Internet
Wi-Fi CERTIFIED ™
■
Recognizable Command
■
Line Interface (CLI) and
intuitive Web GUI
Free firmware updates
■
Industry-leading five-year
■
North American warranty
NetVanta 1335
Multiservice Access Router
The NetVanta ® 1335 Multiservice Access
Router is a performance-enhanced platform
that addresses the need of multiple networking
devices in a single compact platform. The
NetVanta 1335 integrates a modular IP access
router, 802.11a/b/g Wireless Access Point (WAP)
24-port Layer 3 Power over Ethernet (PoE) switch,
firewall, VPN appliance, and DSU/CSU, all in one
platform. In addition, the NetVanta 1335, injected
with RapidRoute technology, delivers enhanced-
™
performance necessary for IP telephony, corporate
connectivity and Internet access, even with
advanced services enabled.
Modular Hardware
The NetVanta 1335 is a modular, 1U-high, rack-
mountable metal chassis that offers a single-slot
to house any of the NetVanta Series of Network
Interface Modules (NIMs) and Dial backup
Interface Module (DIMs). The NetVanta 1335
also includes Gigabit SFP/1000Base-T Ethernet
interface(s) for uplink or stacking capabilities and
a fully managed, non-blocking, 24-port, Layer 3
switch. In addition, the NetVanta 1335 also offers
an 802.3af PoE version, delivering the full 15 watts
per port.
Standards Protocols
®
Based on the ADTRAN Operating System (AOS),
the NetVanta 1335 allows for the support of stan-
dards-based switching and routing functions.
Switching features include 802.1Q VLANs, Storm
Control, 802.1D and 802.1w Spanning/ Rapid
Spanning Tree, Link Aggregation, Port Mirroring,
GVRP, and Link Layer Discovery Protocol (LLDP) to
auto-discover neighboring Ethernet devices. For IP
routing it enables fast, accurate network conver-
gence using routing protocols such as BGP , OSPF,
RIP, static and default routes, and demand routing.
Quality of Service (QoS)
The NetVanta 1335 supports QoS to prioritize
mission-critical traffic and control network conges-
tion at various layers of the OSI model. On the
LAN, the NetVanta 1335 offers 802.1p and DiffServ
Class of Service (CoS). To assign priority to traffic,
Weighted Round Robin and Strict Priority Queuing
is used with four egress queues per port. For the
WAN, DiffServ marking, Low Latency Queuing,
Weighted Fair Queuing (WFQ), and Class-based
WFQ provide priority for IP packets routed over
the WAN. Together these features offer a powerful
end-to-end QoS story.
VoIP Ready
In combination with the QoS features, a special-
ized SIP Application Layer Gateway (ALG) allows
SIP traffic to traverse NAT enabled firewalls. For
corporate networks, this interoperability allows
IP PBXs, phones and other SIP-based devices to
set up, tear down and pass voice and call control
messages seamlessly through the integral NAT-
enabled firewall.
Wi-Fi ®
The Wi-Fi version of the NetVanta 1335 concur-
rently provides an 802.11b/g and 802.11a radio
support at speed up to 54Mbps. Standard wireless
security features apply, with advanced business-
class needs, including multiple SSIDs, disabled
SSID broadcasts, 802.1x for user-based authenti-
cation, WPA and WPA2 pre-shared keys, with TKIP
and AES encryption. The NetVanta 1335 with
Wi-Fi also employs Virtual Access Points (VAPs),
the equivalent of wireless Virtual LANS (VLANs).
VAPs allow customers to securely segment their
wireless network like that of their wired network.
Security
The NetVanta 1335 provides a powerful, high
performance stateful inspection firewall to stop
intruders and common Denial of Service (DoS)
attacks. In addition, a variety of data security
features including MAC-based port security,
SSH and SSL for encrypted user login, and user
authentication using TACACS+, RADIUS or RSA
SecurID. For data integrity and added security, the
NetVanta 1335 supports 500 IPSec VPN tunnels
using DES, 3DES or AES encryption.
Administration
The AOS offers both a Command Line Interface
(CLI) that mimics the widely deployed, industry
de facto standard and an intuitive Web-based GUI
with step-by-step configuration wizards.
