Unit Installation
5. UNIT INSTALLATION
The instructions and guidelines provided in this section cover hardware installation topics such as mounting
options, supplying power to the unit, and installing option cards. These instructions are presented as follows:
• Mounting Options on page 51
• Supplying Power to the Unit on page 53
• Installing Dial Backup and Network Interface Modules on page 54
• Installing the NetVanta VPN Accelerator Card (included in P/N 4200368L1) on page 57
For information on configuring a specific application, refer to the quick configuration documents provided on
the ADTRAN OS System Documentation CD or the Command Line Reference Guide (also included on your
CD).
To prevent electrical shock, do not install equipment in a wet location or during a
lightning storm.
Electronic modules can be damaged by static electrical discharge. Before handling
modules, put on an antistatic discharge wrist strap to prevent damage to electrical
components. Place modules in antistatic packing material when transporting or storing.
When working on modules, always place them on an approved antistatic mat that is
electrically grounded.
Tools Required
The customer-provided tools required for the hardware installation of the NetVanta are:
• Ethernet cables
• Network cables (module dependent)
• DSX-1 cable (T1/FT1 + DSX-1 module only)
• DBU cable (dial backup functions require an optional DIM)
• Phillips-head screwdriver (rack-mounted applications only)
To access the command line interface (CLI) of the NetVanta, you will also need a VT100
terminal or PC with terminal emulation software and a console port cable. Instructions on
how to access the CLI are given in the Command Reference Guide (provided on the
ADTRAN OS System Documentation CD).
