NetVanta 1000/1000R Series Hardware Installation Guide
NetVanta 1335 Rear Panel Interfaces
NIM Option Slot
The NIM option slot accepts a variety of NIM option modules (refer to Option Modules on page 34).
CompactFlash
®
The CompactFlash
NetVanta 1335 supports only ADTRAN-provided CompactFlash (16 MB to 1 GB) (refer to the part
number on the front cover of this manual).
CONSOLE Interface
The CONSOLE interface is an EIA-232 serial port (DCE) which provides for local management and
configuration (via a DB-9 female connector).
Connection directly to an external modem requires a cross-over cable.
Antenna Connectors
The ANT 1 and ANT 2
dual-band antennas for concurrent 802.11a and 802.11b/g connections.
Power Connection
The rear panel has a power input to the AC universal power supply. Please refer to Supplying Power to
the Unit on page 53 for connection details.
NetVanta 1524ST
The NetVanta 1524ST is a Layer 2 managed switch housed in a 1U-high rack-mountable metal enclosure that
includes a universal AC power supply. The front panel contains 24 10/100/1000BaseT Ethernet interfaces that
are accessed via standard RJ-45 connectors. Four of these twenty-four interfaces can be used in either copper or
fiber mode. Four industry-standard SFP slots (supporting industry-standard SFP modules) are available for
high-speed uplink or stacking requirements. The switch is managed through an EIA-232
(DB-9).
This section includes a list of features, a list of shipping contents, and a description of the unit's front and rear
panel designs. For additional information, refer to the following sections:
• Product Specifications on page 33
• Mounting Options on page 51
• Supplying Power to the Unit on page 53
For information on switch configuration for a specific application, refer to the quick configuration documents
provided on the ADTRAN OS System Documentation CD shipped with your base unit. For details on the
command line interface, refer to the Command Reference Guide (also included on your CD).
61200500L1-34L
slot supplies nonvolatile configuration and compressed code storage. The
ports (NetVanta 1335 WiFi and NetVanta 1335 WiFi PoE only) support two
Copyright © 2007 ADTRAN, Inc.
Physical Descriptions
port
CONSOLE
29
