Physical Descriptions
NetVanta 1224ST Rear Panel Interfaces
CONSOLE Interface
The interface is an EIA-232 serial port (DCE) which provides for local management and
CONSOLE
configuration (via a DB-9 female connector).
Connection directly to an external modem requires a cross-over cable.
Power Connection
The rear panel has a power input to the AC universal power supply. Please refer to Supplying Power to
the Unit on page 53 for connection details.
NetVanta 1224R
The NetVanta 1224R and NetVanta 1224R PoE are managed switches housed in a 1U-high rack-mountable
metal enclosure that includes a universal AC power supply. The front panel contains 24 10/100BaseT Ethernet
interfaces (RJ-45). The NetVanta 1224R PoE version provides the ability to detect attached powered devices
(PDs) and deliver 48 VDC to the PDs via existing CAT5 cabling. Both units contain a single Network Interface
Module (NIM) slot on the rear panel to support the following modules:
• 1200861L1
• 1202862L1
• 1202863L1
• 1200872L1
• 1200868E1/L1
• 1200878E1/L1
• 1200866E1/L1
• 1200867L1
• 1200869E1/L1
• 1200889E1/L1
• 1200864L1
• 1200865L1
• 1200875L1
• 1200886L1
This section includes a list of features, a list of shipping contents, and a description of the unit's front and rear
panel designs. For additional information, refer to the following sections:
• Product Specifications on page 33
• Mounting Options on page 51
• Supplying Power to the Unit on page 53
For information on router configuration for a specific application, refer to the quick configuration documents
provided on the ADTRAN OS System Documentation CD shipped with your base unit. For details on the
command line interface, refer to the Command Reference Guide (also included on your CD).
20
NetVanta 1000/1000R Series Hardware Installation Guide
56K/64K NIM
T1/FT1 NIM
T1/FT1 + DSX-1 NIM
Dual T1 NIM
E1/FE1 NIM
E1/FE1 + G.703 Drop NIM
Serial Interface Module
SHDSL NIM
ADSL NIM, Annex A
ADSL NIM, Annex B
Analog Modem DIM
ISDN BRI DIM
ISDN S/T DIM
Serial DIM
