ADTRAN NetVanta 1224ST Hardware Installation Manual page 26

Physical Descriptions
Power Connection
The rear panel of the NetVanta 1224STR (AC) and NetVanta 1224STR PoE have a power input for
connection to an AC universal power supply. The NetVanta 1224STR (DC) connects to a centralized
DC power source via a four-position power connector. Please refer to Supplying Power to the Unit on
page 53 for connection details.
NetVanta 1335
All NetVanta 1335 Series units are managed switches plus multiservice routers housed in a 1U-high
rack-mountable metal enclosure that includes a universal AC power supply. The NetVanta 1335 PoE and
NetVanta 1335 WiFi PoE provide the ability to detect attached powered devices (PDs) and deliver 48 VDC to
the PDs via existing CAT5 cabling. The NetVanta 1335 WiFi Series units operate as wireless bridges for local
area networks (LANs). A dual radio design with two dual-band external antennas is used to support concurrent
802.11a and 802.11b/g connections. The NetVanta 1335 Series front panels contain 24 10/100BaseT Ethernet
interfaces and two Gigabit Ethernet interfaces accessed via a fixed RJ-45 connector or SFP slots for fiber
connectivity. The NetVanta 1335 WiFi Series front panels contain 24 10/100BaseT Ethernet interfaces and one
Gigabit Ethernet interface accessed via a fixed RJ-45 connector or SFP slot. All NetVanta 1335 Series units
include IPSec VPN support (without further software upgrades) and expandable memory via CompactFlash
and SODIMM slots. NetVanta 1335 Series units also contain one NIM slot on the rear panel to support the
following modules in data applications:
• 1200861L1
• 1202862L1
• 1202863L1
• 1200872L1
• 1200868E1/L1
• 1200878E1/L1
• 1200866E1/L1
• 1200867L1
• 1200869E1/L1
• 1200889E1/L1
• 1200864L1
• 1200865L1
• 1200875L1
This section includes a list of features, a list of shipping contents, and a description of the front and rear panel
designs. For additional information, refer to the following sections:
• Product Specifications on page 33
• Mounting Options on page 51
• Supplying Power to the Unit on page 53
For information on router configuration for a specific application, refer to the quick configuration documents
provided on the ADTRAN OS System Documentation CD shipped with your base unit. For details on the
command line interface, refer to the Command Reference Guide (also included on your CD).
NetVanta 1335 Shipping Contents
Each NetVanta 1335 unit is shipped in its own cardboard shipping carton. Open each carton carefully, and avoid
deep penetration into the carton with sharp objects.
26
NetVanta 1000/1000R Series Hardware Installation Guide
56K/64K NIM
T1/FT1 NIM
T1/FT1 + DSX-1 NIM
Dual T1 NIM
E1/FE1 NIM
E1/FE1 + G.703 Drop NIM
Serial Interface Module
SHDSL NIM
ADSL NIM, Annex A
ADSL NIM, Annex B
Analog Modem DIM
ISDN BRI DIM
ISDN S/T DIM
Copyright © 2007 ADTRAN, Inc.
®
61200500L1-34L
