  • Page 1 NetVanta 1224STR DC Hardware Installation Guide 1200590E1 NetVanta 1224STR DC 4200368L1 Enhanced Feature Pack (Hardware and Software) for IPSec VPN Upgrade 1200861L1 NetVanta 56K/64K Network Interface Module 1200862L2#NEBS NetVanta T1/FT1 NEBS Network Interface Module 1202862L1 NetVanta T1/FT1 Network Interface Module...
  • Page 2 To the Holder of the Manual The contents of this manual are current as of the date of publication. ADTRAN reserves the right to change the contents without prior notice. In no event will ADTRAN be liable for any special, incidental, or consequential damages or for commercial losses even if ADTRAN has been advised thereof as a result of issue of this publication.
  • Page 3 NetVanta 1224STR DC Hardware Installation Guide Conventions Conventions Notes provide additional useful information. Cautions signify information that could prevent service interruption or damage to the equipment. Warnings provide information that could prevent injury or endangerment to human life. 61200590E1-34B Copyright © 2013 ADTRAN, Inc.
  • Page 4 Safety Instructions NetVanta 1224STR DC Hardware Installation Guide Safety Instructions When using your telephone equipment, please follow these basic safety precautions to reduce the risk of fire, electrical shock, or personal injury: 1. Do not use this product near water, such as a bathtub, wash bowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.
  • Page 5 Advance notification and the opportunity to maintain uninterrupted service are given. 4. If experiencing difficulty with this equipment, please contact ADTRAN for repair and warranty information. The telephone company may require this equipment to be disconnected from the network until the problem is corrected, or it is certain the equipment is not malfunctioning.

  • Page 6: Fcc Radio Frequency Interference Statement

    FCC Radio Frequency Interference Statement NetVanta 1224STR DC Hardware Installation Guide FCC Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 7 NetVanta 1224STR DC Hardware Installation Guide Industry Canada Compliance Information Industry Canada Compliance Information Notice: The Industry Canada label applied to the product (identified by the Industry Canada logo or the “IC:” in front of the certification/registration number) signifies that the Industry Canada technical specifications were met.
  • Page 8 Denial of Service (DoS) attacks, loss or theft of data, and the unauthorized or illegal use of said equipment. ADTRAN OFFERS NO WARRANTIES, EITHER EXPRESSED OR IMPLIED, REGARDING THE PREVENTION, DETECTION, OR DETERRENCE OF TOLL FRAUD, NETWORKING ATTACKS, OR UNAUTHORIZED, ILLEGAL, OR IMPROPER USE OF ADTRAN EQUIPMENT OR SOFTWARE.

  • Page 9: Table Of Contents

    Connector Pin Definitions..........43 61200590E1-34B Copyright © 2013 ADTRAN, Inc.
  • Page 10 Table of Contents NetVanta 1224STR DC Hardware Installation Guide Copyright © 2013 ADTRAN, Inc. 61200590E1-34B...

  • Page 11: List Of Figures

    Figure 16. Grounding the NetVanta 1224STR DC ........
  • Page 12 List of Figures NetVanta 1224STR DC Hardware Installation Guide Copyright © 2013 ADTRAN, Inc. 61200590E1-34B...
  • Page 13 Table A-14. ISDN S/T DBU Connector Pinouts..........48 61200590E1-34B Copyright © 2013 ADTRAN, Inc.
  • Page 14 List of Tables NetVanta 1224STR DC Hardware Installation Guide Copyright © 2013 ADTRAN, Inc. 61200590E1-34B...

  • Page 15: Introduction

    PHYSICAL DESCRIPTION The NetVanta 1224STR DC is a managed switch housed in a 1U-high rack-mountable metal enclosure that includes a DC power supply. The front panel contains 24 10/100Base-T Ethernet interfaces (RJ-45), one Gigabit Ethernet interface that provides one fixed RJ-45 connector, and one standard small form-factor pluggable (SFP) slot for fiber connectivity.

  • Page 16: Module Network Interface

    ISDN S/T DIM SFP Module Slots The NetVanta 1224STR DC supports one SFP slot. It accepts a number of industry standard SFP modules. The SFP modules provide Gigabit Ethernet fiber connectivity for high-speed uplinks or switch stacking. For a list of supported SFP modules, visit the ADTRAN website at http://www.adtran.com.

  • Page 17: Front Panel Design

    All necessary power cords Front Panel Design The NetVanta 1224STR DC front panel is shown below. Table 1 on page 18 describes all of the LEDs, and Appendix A on page 43 shows the connector pinouts. NetVanta 1224STR DC Front Panel Features Status LEDs The status LEDs are located to the lower left of RJ-45 port 1.

  • Page 18: Table 1. Front Panel Led Descriptions

    Connection directly to an external modem requires a cross-over cable. Power Connection The NetVanta 1224STR DC connects to a centralized DC power source via a four-position power connector. Please refer to Supplying Power to the Unit on page 38 for connection details.

  • Page 19: Option Modules

    Option Modules OPTION MODULES The NetVanta 1224STR DC supports several option modules designed to meet a variety of networking requirements. The option modules include plug-in NIMs and plug-on DIMs. NIMs are cards that plug directly into the option module slot located on the rear of the base unit. These cards provide the following types of interfaces: •...

  • Page 20: Network Interface Modules

    Option Modules NetVanta 1224STR DC Hardware Installation Guide Network Interface Modules NetVanta 56K/64K NIM (P/N 1200861L1) The 56K/64K NIM (shown in Figure 3) provides a DDS WAN interface for the NetVanta. This module provides a single 56K or 64K DDS network interface. See Table A-5 on page 45 for the WAN-DDS connector pinouts, and Table A-13 on page 48 for the DBU connector pinouts.

  • Page 21: Figure 4. Netvanta T1/Ft1 Nim

    NetVanta 1224STR DC Hardware Installation Guide Option Modules NetVanta T1/FT1 NIM (P/N 1202862L1) The T1/FT1 NIM (shown in Figure 4) provides a T1 WAN interface for the NetVanta. This module provides a full T1 or fractional T1 network interface. See Table A-6 on page 45 for the WAN-T1 connector pinouts, and Table A-13 on page 48 for the DBU connector pinouts.

  • Page 22: Figure 5. Netvanta T1/Ft1 Nebs Nim

    The T1/FT1 NEBS NIM (see Figure 5) T1 WAN interface for the NetVanta 1224STR DC. The T1 NEBS NIM is NEBS Level 3 compliant, and provides a full T1 or fractional T1 network interface. See Table A-6 on page 45 for the WAN-T1 connector pinouts.

  • Page 23: Figure 6. Netvanta T1/Ft1 + Dsx-1 Nim

    NetVanta 1224STR DC Hardware Installation Guide Option Modules NetVanta T1/FT1 + DSX-1 NIM (P/N 1202863L1) The T1/FT1 + DSX-1 NIM (see Figure 6) provides a T1 WAN interface for the NetVanta, a full or fractional T1 network interface, and a DSX-1 interface. See the pinouts in Table A-6 on page 45 for the WAN-T1 connector, Table A-8 on page 46 for the DSX-1 connector, and Table A-13 on page 48 for the DBU connector pinouts.

  • Page 24: Figure 7. Netvanta Dual T1 Nim

    Option Modules NetVanta 1224STR DC Hardware Installation Guide NetVanta Dual T1 NIM (P/N 1200872L1) The NetVanta Dual T1 NIM (see Figure 7) provides two T1 WAN interfaces for the NetVanta. See Table A-6 on page 45 for the pinouts. See Table A-13 on page 48 for the DBU connector pinouts. An optional DIM is required for dial backup applications.

  • Page 25: Figure 8. Netvanta E1/Fe1 Nim

    NetVanta 1224STR DC Hardware Installation Guide Option Modules NetVanta E1/FE1 NIM (P/N 1200868E1/L1) The NetVanta E1/FE1 NIM (see Figure 8) provides a WAN-E1 interface for the NetVanta meeting the requirements of ITU-T G.703/G.704. The module provides a single 2.048 Mbps network interface. See Table A-7 on page 45 for the pinouts.

  • Page 26: Figure 9. Netvanta E1/Fe1 + G.703 Drop Nim

    Option Modules NetVanta 1224STR DC Hardware Installation Guide NetVanta E1/FE1 + G.703 Drop NIM (P/N 1200878E1/L1) The NetVanta E1/FE1 + G.703 Drop NIM (see Figure 9) provides a single WAN-E1 interface (2.043 Mbps) with user-selectable TS0 assignment, and a G.703 drop port that may be used to drop and insert traffic to an E1 PBX.

  • Page 27: Figure 10. Netvanta Serial Nim

    10) can be configured by the user as a V.35, X.21 (V.11), or EIA 530 interface. This module supports rates up to a maximum of 10 Mbps. An additional V.35 (ADTRAN P/N 1200873L1), X.21 (ADTRAN P/N 1200874L1), or EIA 530 (ADTRAN P/N 1200883L1) cable is required (refer to Caution, below).

  • Page 28: Figure 11. Netvanta Shdsl Nim, Annex A

    Option Modules NetVanta 1224STR DC Hardware Installation Guide NetVanta SHDSL NIM, Annex A (P/N 1200936E1) The NetVanta SHDSL NIM, Annex A (shown in Figure 11) provides a WAN SHDSL interface for the NetVanta. See Table A-10 on page 46 for the SHDSL connector pinouts.

  • Page 29: Figure 12. Netvanta Shdsl Nim, Annex B

    NetVanta 1224STR DC Hardware Installation Guide Option Modules NetVanta SHDSL NIM, Annex B (P/N 1200937E1) The NetVanta SHDSL NIM, Annex B (shown in Figure 12) provides a WAN SHDSL interface for the NetVanta. See Table A-10 on page 46 for the SHDSL connector pinouts.

  • Page 30: Figure 13. Netvanta Adsl Nim, Annex A

    Option Modules NetVanta 1224STR DC Hardware Installation Guide NetVanta ADSL NIM, Annex A (P/N 1202869E1) The NetVanta ADSL NIM, Annex A (see Figure 13) adds ADSL capability to the NetVanta. The module provides a single ADSL, ADSL2, or ADSL2+ network interface to support rates up to 25 Mbps. See Table A-11 on page 47 for the pinouts.

  • Page 31: Figure 14. Netvanta Adsl Nim, Annex B

    NetVanta 1224STR DC Hardware Installation Guide Option Modules NetVanta ADSL NIM, Annex B (P/N 1202889E1) The NetVanta ADSL NIM, Annex B (see Figure 14) adds ADSL capability to the NetVanta. See Table A-11 on page 47 for the pinouts. The ADSL NIM supports an optional DIM for dial backup applications. See Table A-13 on page 48 for the DBU connector pinouts.

  • Page 32: Dial Backup Interface Modules

    Option Modules NetVanta 1224STR DC Hardware Installation Guide Dial Backup Interface Modules NetVanta Analog Modem DIM (P/N 1200864L1) The Analog Modem DIM provides a modem with data rates up to 33.6 kbps for the NetVanta. This DIM is a plug-on card that connects to the NIM. For installation instructions, refer to Installing Dial Backup and Network Interface Modules on page 39 .

  • Page 33: Netvanta Isdn Bri Dim (P/N 1200865L1)

    NetVanta 1224STR DC Hardware Installation Guide Option Modules NetVanta ISDN BRI DIM (P/N 1200865L1) The NetVanta ISDN BRI DIM provides dial backup access to the public switched telephone network (PSTN) via Basic Rate ISDN for the NetVanta. This DIM is a plug-on module that connects to the NIM. For installation instructions, refer to Installing Dial Backup and Network Interface Modules on page 39 .

  • Page 34: Netvanta Isdn S/T Dim (P/N 1200875L1)

    Option Modules NetVanta 1224STR DC Hardware Installation Guide NetVanta ISDN S/T DIM (P/N 1200875L1) The NetVanta ISDN S/T DIM provides dial backup access to the PSTN via Basic Rate ISDN for the NetVanta. This DIM is a plug-on module that connects to the NIM. For installation instructions, refer to Installing Dial Backup and Network Interface Modules on page 39 .

  • Page 35: Unit Installation

    To prevent electrical shock, do not install equipment in a wet location or during a lightning storm. • The NetVanta 1224STR DC is intended to be installed, maintained, and serviced by qualified service personnel only and should be installed in a restricted access location as described in UL/IEC 60950-1.

  • Page 36: Mounting Options

    The unit may be installed in rackmount, wallmount, or tabletop configurations. The following sections provide step-by-step instructions for rack mounting and wall mounting. If you have purchased the VPN Accelerator Card for your NetVanta 1224STR DC, install it first (refer to Installing the NetVanta VPN Accelerator Card (included in P/N 4200368L1) on page 41 ).

  • Page 37: Figure 15. Wallmount Installation

    NetVanta 1224STR DC Hardware Installation Guide Unit Installation Wall Mounting the NetVanta By following these instructions exactly, the NetVanta can be safely mounted to the wall. • To avoid damaging the unit, use only the screws included in the shipment when attaching mounting ears to the chassis.

  • Page 38: Supplying Power To The Unit

    Unit Installation NetVanta 1224STR DC Hardware Installation Guide Supplying Power to the Unit The NetVanta 1224STR DC connects to a centralized DC power source via the four-position power connector on the rear of the chassis (see Figure 16 below). Power and ground connections require copper conductors and a ring lug.

  • Page 39: Installing Dial Backup And Network Interface Modules

    NetVanta 1224STR DC Hardware Installation Guide Unit Installation Figure 16. Grounding the NetVanta 1224STR DC Installing Dial Backup and Network Interface Modules The DIM plugs on to the NIM. The NIM is then installed into the rear panel option module slot. The following tables list the installation steps.

  • Page 40: Figure 17. Installing Dims

    Unit Installation NetVanta 1224STR DC Hardware Installation Guide Figure 17. Installing DIMs Instructions for Installing the DIMs Step Action Remove power from the unit. If the NIM is already in the NetVanta chassis, remove all cables, release the pins at both edges of the NIM front panel, and slide the module out of the chassis.

  • Page 41: Installing The Netvanta Vpn Accelerator Card (Included In P/N 4200368L1)

    The optional VPN Accelerator card plugs into a 32-bit PCI slot and is designed to be used in the NetVanta 1224STR DC to provide encryption/decryption and security acceleration services. The card provides the following security services to the host processor: DES, triple-DES (3DES), AES, SHA-1, MD5, and random number generation.

  • Page 42: Figure 19. Netvanta Vpn Accelerator Card Installation

    Unit Installation NetVanta 1224STR DC Hardware Installation Guide Instructions for Installing the NetVanta VPN Accelerator Card Step Action Remove power from the unit. Remove the screws holding the base unit and the cover together and, if necessary, two mounting brackets (see Figure 19).

  • Page 43: Appendix A. Connector Pin Definitions

    Clear to Send Tied to pin 1 (output) — Unused Table A-2. SFP Slot Pinouts Name Name TGND RGND TX FAULT TX DISABLE MOD DEF(2) RGND MOD DEF(1) VccR MOD DEF(0) VccT RATE SELECT TGND RGND RGND TGND 61200590E1-34B Copyright © 2013 ADTRAN, Inc.

  • Page 44: Table A-3. 10/100Base-T Ethernet Port Pinouts

    Appendix A. Connector Pin Definitions NetVanta 1224STR DC Hardware Installation Guide Table A-3. 10/100Base-T Ethernet Port Pinouts Name Description Transmit Positive Transmit Negative Receive Positive 4, 5 — Unused Receive Negative 7, 8 — Unused Table A-4. 1000Base-T Gigabit Ethernet Port Pinouts...

  • Page 45: Table A-5. Wan-Dds Connector Pinouts

    NetVanta 1224STR DC Hardware Installation Guide Appendix A. Connector Pin Definitions Network Interface Module Pinouts Table A-5. WAN-DDS Connector Pinouts Name Description Transmit data to the network–Ring 1 Transmit data to the network–Tip 1 — Unused Receive data from the network–Tip Receive data from the network–Ring...

  • Page 46: Table A-8. Dsx-1 Connector Pinouts

    Appendix A. Connector Pin Definitions NetVanta 1224STR DC Hardware Installation Guide Table A-8. DSX-1 Connector Pinouts Name Description Transmit data toward the DTE–Ring Transmit data toward the DTE–Tip — Unused Receive data from the DTE–Ring 1 Receive data from the DTE–Tip 1 —...

  • Page 47: Table A-11. Wan-Adsl Connector Pinouts

    NetVanta 1224STR DC Hardware Installation Guide Appendix A. Connector Pin Definitions Table A-11. WAN-ADSL Connector Pinouts Name Description 1, 2 — Unused ADSL Ring ADSL Tip 5, 6 — Unused Table A-12. Serial to Cable Connector Pinouts Serial V.35 X.21...

  • Page 48: Table A-13. Analog Modem And Isdn Bri Dbu Connector Pinouts

    Appendix A. Connector Pin Definitions NetVanta 1224STR DC Hardware Installation Guide Dial Backup Interface Module Pinouts (DBU Connector) An optional DIM is required for dial backup applications. Table A-13. Analog Modem and ISDN BRI DBU Connector Pinouts Name Description —...
