The EDID properties currently assigned to each input are displayed in the table of inputs.
The audio input format listed in an EDID is determined by the audio input format selected
on the
Input Configuration
Up to three EDID can be stored on the device as custom EDID files. Audio settings from
custom EDID files take priority over current settings on the input.
If an analog custom EDID file is assigned to a digital input or a digital custom
NOTE:
EDID file assigned to an analog input, the display may not appear correctly.
Filtering Available EDID
Use the Filter tab to limit the number of available EDID displayed in the Favorites ,
Connected Outputs and Available EDIDs sections (see
,
previous page).
1. From the Resolution drop-down menu (
2. From the Refresh Rate drop-down menu (
Assigning EDID
To assign EDID to selected inputs:
1. From the Inputs group box (table of inputs,
for the desired inputs
2.
From the Favorites , Available EDIDs , or Connected Outputs panel on the
left, select the desired EDID (
3.
Then either:
• From the Inputs group box (
one or more selected inputs, OR
• Drag and drop EDID image from the Favorites , Available EDIDs , or
Connected Outputs
To assign EDID to all inputs:
1. From the Favorites , Available EDIDs , or Connected Outputs panel (
select an EDID.
2. From the Inputs group box, click the Assign to All button (
NOTE: Unchecked inputs are ignored when assigning an EDID to all inputs.
To match the selected inputs to the current output resolution:
Matching the output resolution is the default value for all inputs.
1. From the Inputs group box (table of inputs,
for the desired inputs.
2. In the Output Resolution panel, click the Match Output button (
page.
) select a specific resolution or Any .
2
) select a specific refresh rate or Any .
3
) on the right, select the check boxes
4
).
1
), click the Assign button (
4
panels to one or more selected inputs.
) on the right, select the check boxes
4
DSC 301 HD • Product Configuration Software
figure 40, , on the
1
) to assign EDID to
5
),
1
).
6
).
7
52
