Extron electronics DSC 301 HD User Manual page 10

• Front panel security lockout — This feature can block all front panel control, or limit
front panel to input selection only. All functions however, are available through RS-232
control.
• RS-232 control port — Enables the use of serial commands for complete control
and configuration or integrated into a control system. Extron products use the SIS
Simple Instruction Set command protocol, a set of basic ASCII code commands that
allow for quick and easy programming.
• Front-panel USB configuration port — Enables easy configuration without having
to access the rear panel.
1 inch (2.5 cm) high, half rack width metal enclosure
•
• Includes LockIt HDMI cable lacing brackets
• Energy-efficient external universal power supply included — Provides worldwide
power compatibility, low power consumption, and reduced operating costs.
ATTENTION:
• If not provided with a power supply, this product is intended to be supplied by
a UL Listed power source marked "Class 2" or "LPS" and rated output 12Vdc,
minimum 0.5A.
•
Si ce produit ne dispose pas de sa propre source d'alimentation électrique, il doit
être alimenté par une source d'alimentation certifiée UL de classe 2 ou LPS et
paramétré à 12 V et 0,5 A minimum
DSC 301 HD • Introduction
-
™
4
