Command ASCII Command
(host to scaler)
Horizontal position (image)
Specific value
EX1%HCTR}
Increment value
E+HCTR}
Decrement value
E-HCTR}
View
EHCTR}
Vertical position (image)
Specific value
EX1%VCTR}
Increment value
E+VCTR}
Decrement value
E-VCTR}
View
EVCTR}
Horizontal size (image)
Specific value
EX1^HSIZ}
Increase size
E+HSIZ}
Decrease size
E-HSIZ}
View
EHSIZ}
Vertical size (image)
Specific value
EX1^VSIZ}
Increase size
E+VSIZ}
Decrease size
E-VSIZ}
View
EVSIZ}
Compound Image Position and Size
Specific value
EX1%*X1%*X1^*X1^XIMG}
View
EXIMG}
Presets
User presets
Recall preset 1*X1(.
Save preset
1*X1(,
Delete/clear preset
EX1*X1(PRST}
User preset name
Write name
E1*X1(,X1#PNAM}
Read name
E1*X1(PNAM}
NOTE:
Unassigned presets = "
for previously saved presets.
NOTE:
X1# = Text label/preset name, up to 16 characters
X1% = Horizontal or vertical position:
X1^ = Horizontal or vertical size:
1 3
X1( = User preset, -
[unassigned]". To restore a default user preset name, enter a single space character for
-2200 +2200
to
0000 4400
to
for each input
Response
(scaler to host)
HctrX1%]
HctrX1%]
HctrX1%]
X1%]
VctrX1%]
VctrX1%]
VctrX1%]
X1%]
HsizX1^]
HsizX1^]
HsizX1^]
X1^]
VsizX1^]
VsizX1^]
VsizX1^]
X1^]
XimgX1%*X1%*X1^*X1^]
X1%*X1%*X1^*X1^]
1RprX1(]
1SprX1(]
PrstX1*X1(]
Pnam1*X1(,X1#]
X1#]
