Levelflex FMP55 FOUNDATION Fieldbus
Endress+Hauser
Step Block
5 SETUP (TRDSUP)
6 SETUP (TRDSUP)
7 SETUP (TRDSUP)
8 SETUP (TRDSUP)
9 SETUP (TRDSUP)
10 SETUP (TRDSUP)
11 SETUP (TRDSUP)
12 SETUP (TRDSUP)
13 SETUP (TRDSUP)
1) only available for coated probes and "Tank type" = "Bypass/pipe"
NOTICE
Wrong dielectric constant of the lower medium may cause a measuring error.
‣
If, in the case of the operating mode 32940: Interface with capacitance the lower
medium is no water, it is necessary to specify its dielectric constant (DC value). Block:
ADV_SETUP (TRDASUP); parameter: DC vaylue lower medium
(dc_value_lower_medium).
Commissioning (block-based operation)
Parameter Action
DC value (dc_value) Enter dielectric
constant of the upper
medium.
Empty calibration Enter the distance E
(empty_calibration) between the reference
point R and the
minimum level (0%).
Full calibration Enter distance F
(full_calibration) between the minimum
(0%) and maximum
(100%) level.
Level (level) Displays the measured
level L.
Interface (interface) Displays the interface
height L
Distance Displays the distance D
(filtered_dist_val) between the reference
point R and the level L.
Interface distance Displays the distance
(interface_distance) D between the
I
reference point R and
the interface L
Signal quality Displays the signal
(signal_quality) quality of the level
echo.
Confirm distance Compare the displayed
(confirm_distance) distance to the real
distance in order to
start the recording of
the mapping curve.
Selection:
• 179: Manual map
• 32847: Delete all
• 32859: Distance ok
• 32860: Distance too
big
• 32861: Distance too
small
• 32862: Distance
unknown
• 33100: Tank empty
.
I
.
I
