Operating menu
Level signal
Navigation
Prerequisite
Description
User interface
Additional information
Launch signal
Navigation
Prerequisite
Description
User interface
Additional information
Interface signal
Navigation
Prerequisite
Description
User interface
206
 Diagnostics → Device check → Level signal
Device check has been performed.
Displays result of the device check for the level signal.
• Check not done
• Check not OK
• Check OK
For Level signal = Check not OK: Check the mounting position of the device and the
dielectric constant of the medium.
 Diagnostics → Device check → Launch signal
Device check has been performed.
Displays result of the display check for the launch signal.
• Check not done
• Check not OK
• Check OK
For Launch signal = Check not OK: Check the mounting position of the device. In non-
metallic vessels use a metal plate or a metal flange.
 Diagnostics → Device check → Interface signal
• Operating mode (→  129) = Interface or Interface with capacitance
• Device check has been performed.
Displays result of the device check for the interface signal.
• Check not done
• Check not OK
• Check OK
Levelflex FMP55 FOUNDATION Fieldbus
Endress+Hauser
