AirCheck G2 Wireless Tester
User Manual
2 Press the Connect*

network is not configured - Configure Now?" is displayed.

If Connect does not have an asterisk, it is either an open
network or the security credentials have already been
entered.
3 Press OK to continue to the next screen. The popup

"Creating new network in current profile" is displayed
followed by the Select Authentication screen.
4 Highlight the appropriate encryption type and press
Select.
5 Press Next . Depending on the authentication type

that was selected, either the WEP > WEP Key Setup,
Legacy 802.1X > EAP Type Selection, or the WPA/WPA2 >
Set Encryption screen is displayed.
The WPA/WPA2 encryption type was selected for steps 6
through 11. WEP and 802.1X have slightly different
screens.
6 Highlight the encryption type, press Select, and then
press Next. The EAP Type Selection screen is displayed.
7 Highlight the EAP type and press Select.
8 Press Next. The Setup Username/Password screen is
displayed.
button. The popup "This
Note
Select Done only after you have finished entering the
username and password. If you select Done and have
not finished entering the settings, the connection will fail.
You will then have to select Settings > Manage profiles
/ network passwords, select Edit networks, select the
network, and finish entering the security settings.
9 Press Set username, enter the username using the on-
screen keyboard, and Press Save.
10 Press Set password, enter the password, and press
Save.
11 Press Done and the Connect to Network screen is
displayed. AirCheck G2 will then try to connect to the
network and run a series of tests.
AirCheck G2 can only use one set of security credentials
per SSID, even if a SSID has multiple Access Points with
different security settings. Therefore, you may encounter
pressing Connect (no asterisk) and the connection fails.
To Save the profile with your security credentials
A profile is a file which contains the settings you configure for
the tester. Most settings are configured in the Settings
screen. You can have multiple profiles on the tester, but only
use one at a time.
40
Note
Note
