[4] CHECK POINTS OF EVERY 100 HOURS

Changing Engine Oil
CAUTION
• Before changing oil, be sure to stop the engine.
1. Start and warm up the engine for approx. 5 minutes.
2. Place an oil pan underneath the engine.
3. To drain the used oil, remove the drain plug (1) at the bottom of
the engine and drain the oil completely.
4. Screw in the drain plug (1).
5. Fill new oil up to upper line on the dipstick (2).
IMPORTANT
• When using an oil of different manufacture or viscosity
from the previous one, remove all of the old oil.
• Never mix two different types of oil.
• Use the proper SAE Engine Oil according to ambient
temperatures.
• Refer to "4. LUBRICANTS, FUEL AND COOLANT" on page
G-8.
B1830, B2230, B2530
Engine oil capacity
B3030
(1) Drain Plug
(2) Dipstick
(3) Oil Inlet Plug
Adjusting Clutch Pedal Free Travel
1. Stop the engine and remove the key.
2. Slightly depress the clutch pedal and measure free travel at the
top of pedal stroke.
3. If adjustment is needed, loosen the lock nut (2) and turn the
clutch rod (1) to adjust the rod length within acceptable limits.
4. Retighten the lock nut (2).
5. After adjusting, release the clutch pedal and check the
clearance (B). If adjustment is needed, adjust the clearance (B)
with the bolt (3).
Clutch pedal free travel
Factory specification
(A)
(1) Clutch Pedal Rod
(2) Lock Nut
(3) Bolt
G-23
GENERAL
3.0 L
3.2 U.S.qts
2.6 lmp.qts
4.1 L
4.3 U.S.qts
3.6 lmp.qts
(A) Oil level is acceptable within this
range.
9Y1210003GEG0019US0
20 to 30 mm
0.79 to 1.18 in.
(A) Clutch pedal free travel
(B) Clearance (About 8.5 mm,
0.34 in.)
9Y1210003GEG0020US0
