Kubota B1830 Workshop Manual page 384

B1830,B2230,B2530,B3030, WSM
Hydraulic Arm Shaft to Bushing
Hydraulic Arm Shaft (R.H.)
Hydraulic Arm Shaft (L.H.)
Hydraulic Cylinder Bushing (R.H.)
Hydraulic Cylinder Bushing (L.H.)
Item
Clearance
O.D.
O.D.
I.D.
I.D.
8-S4
HYDRAULIC SYSTEM
Factory Specification
0.020 to 0.110 mm
0.0008 to 0.0043 in.
37.925 to 37.950 mm
1.4931 to 1.4941 in.
34.925 to 34.950 mm
1.3750 to 1.3759 in.
37.970 to 38.035 mm
1.4949 to 1.4974 in.
34.970 to 35.035 mm
1.3768 to 1.3793 in.
Allowable Limit
0.30 mm
0.0118 in.
–
–
–
–
9Y1210003HYS0002US0
KiSC issued 05, 2012 A
