CAUTION:
To prevent improper cooling and thermal damage, do not operate the node unless all PCI riser
cages or rear I/O blanks are installed, and do not operate the node unless all PCI slots have
either an expansion slot cover or an expansion board installed.

Remove the air baffle

Procedure
1. Power down the node .
2. Disconnect all peripheral cables from the node .
3. Remove the node from the chassis.
4. Place the node on a flat, level surface.
5. If installed in a 2U node, remove the FlexibleLOM 2U node PCI riser cage assembly.
6. If installed in a 2U node, remove the three-slot PCI riser cage assembly.
7. Remove the air baffle:
• 1U air baffle
44 Remove the air baffle
