c. Install all fan modules and connect the fan cables to the power connectors.
3.
Install the access panel.
WARNING:
Always use at least two people to lift the chassis into the rack. If the chassis is being loaded into
the rack above chest level, a third person must assist with aligning the chassis with the rails while
the other two people support the weight of the chassis .
WARNING:
The chassis is very heavy. To reduce the risk of personal injury or damage to the equipment:
Observe local occupational health and safety requirements and guidelines for manual material
handling.
Remove all installed components from the chassis before installing or moving the chassis.
Use caution and get help to lift and stabilize the chassis during installation or removal, especially
when the chassis is not fastened to the rack.
WARNING:
To avoid risk of personal injury or damage to the equipment, do not stack anything on top of rail-
mounted equipment or use it as a work surface when extended from the rack.
CAUTION:
Always plan the rack installation so that the heaviest item is on the bottom of the rack. Install the
heaviest item first, and continue to populate the rack from the bottom to the top.
4.
Install the chassis into the rack and tighten the thumbscrews.
5.
Install all power supplies.
6.
If removed, install the RCM module.
7.
Install all drives.
8.
If removed, install the security bezel.
9.
Install all nodes into the chassis.
10. Connect all peripheral cables to the nodes.
11. Power up the nodes.
62
Removal and replacement procedures
