Node cabling
SATA and Mini-SAS cabling
B140i 1U node SATA cabling
B140i 2U node SATA cabling
Item
Description
1
SATA 1 cable
2
SATA 2 cable
160
Node cabling
Connection
Mini-SAS connector 1 (SATA x4) on the system
board to Port 1 on the bayonet board
Mini-SAS connector 2 (SATA x4) on the system
board to Port 2 on the bayonet board
