CAUTION:
To prevent improper cooling and thermal damage, do not operate the node unless all PCI riser cages
or rear I/O blanks are installed, and do not operate the node unless all PCI slots have either an
expansion slot cover or an expansion board installed.

Remove the riser cage bracket from the three-slot riser cage assembly

About this task
To remove the component:
Procedure
1. Power down the node .
2. Disconnect all peripheral cables from the node .
3. Remove the node from the chassis .
4. Place the node on a flat, level surface.
5. Remove the three-slot PCI riser cage assembly.
6. Remove the riser cage bracket from the three-slot riser cage assembly.
52 Remove the riser cage bracket from the three-slot riser cage assembly
