Node Rear Panel Leds And Buttons - HP Apollo 2000 System Maintenance And Service Manual
Hide thumbs
Also See for Apollo 2000 System:
- User manual (203 pages) ,
- Maintenance and service manual (136 pages)
Table of Contents
Advertisement
Item
Description
1
Node serial number and iLO label pull tab
2
SUV connector
3
USB 3.0 connector
4
Dedicated iLO port (optional)
5
NIC connector 1
6
NIC connector 2
2U node rear panel components
Item
Description
1
Node serial number and iLO label pull tab
2
SUV connector
3
USB 3.0 connector
4
Dedicated iLO port (optional)
5
NIC connector 1
6
NIC connector 2
Node rear panel LEDs and buttons
•
1U node
Node rear panel LEDs and buttons
133
