HP Apollo 2000 System Maintenance And Service Manual page 172

Expansion boards installed in slot 2 of the FlexibleLOM 2U node riser cage assembly (PN 798184-B21)
Description
Low-profile or single-width PCIe card (such as the
P440 Smart Array controller or P840 Smart Array
controller)
Single-width GPU accelerator (such as the NVIDIA
Quadro M4000 or the NVIDIA Quadro K4200)
Double-width GPU accelerator (such as the NVIDIA
Tesla K40 or the AMD FirePro S9150)
GPU accelerators
Description
NVIDIA Quadro K4200
NVIDIA Quadro M4000
NVIDIA Tesla K40
NVIDIA Tesla M40
NVIDIA Tesla M60
NVIDIA Tesla K80
NVIDIA Tesla P40
NVIDIA Tesla P100
NVIDIA GRID K2
Intel Xeon Phi Coprocessor 5110P
AMD FirePro S9150
AMD FirePro S7150
1
If a single-width GPU accelerator is installed in slot 2 of the FlexibleLOM 2U node riser cage assembly (PN
798184-B21), and the Intel
ambient temperature is 21°C (69.8°F).
2
If a double-width GPU accelerator is installed in slot 2 of the FlexibleLOM 2U node riser cage assembly (PN
798184-B21), and the Intel
ambient temperature is 23°C (73.4°F).
DIMMs
Description
64 GB, quad-rank x4 PC4-2400T-L
128 GB, octal-rank x4 PC4-2400T-L
172 Specifications
1
1
2
2
2
® ®
Xeon Processor E5-2643 v4 is installed in a 2U node, the maximum inlet
® ®
Xeon Processor E5-2643 v4 is installed in a 2U node, the maximum inlet
Maximum inlet ambient temperature
20°C (68°F)
21°C (69.8°F)
23°C (73.4°F)
Maximum inlet ambient temperature
N/A
30°C (86°F)
30°C (86°F)
29°C (84.2°F)
22°C (71.6°F)
22°C (71.6°F)
30°C (86°F) if the server node is installed in the HPE
Apollo r2200 Chassis
25°C (77°F) if the server node is installed in the HPE
Apollo r2600 Chassis or the HPE Apollo r2800
Chassis
24°C (75.2°F) if the server node is installed in the
HPE Apollo r2200 Chassis
20°C (68°F) if the server node is installed in the HPE
Apollo r2600 Chassis
30°C (86°F)
30°C (86°F)
30°C (86°F)
30°C (86°F)
Maximum inlet ambient temperature
25°C (77°F)
29°C (84.2°F)
