RCM module LEDs

Item
Description
1
iLO activity LED Green or flashing green = Network activity
Off = No network activity
2
iLO link LED Green = Linked to network
Off = No network connection
3
iLO link LED Green = Linked to network
Off = No network connection
4
iLO activity LED Green or flashing green = Network activity
Off = No network activity
For more information, see "RCM module."

PCIe riser board slot definitions

Single-slot left PCI riser cage assembly (PN 798178-B21)
