4.
If installed, remove the security bezel.
5.
Remove all drives.
6.
If installed, remove the RCM module.
7.
Remove all power supplies.
8.
Remove the chassis from the rack.
9.
Remove the access panel.
10. Remove all fan modules.
11. Disconnect the fan power cable assemblies from the fan cages.
12. Remove the fan cages.
Right fan cage
Left fan cage

Remove the chassis PDB assembly

To remove the component:
1.
Power down the system.
2.
Disconnect all peripheral cables from the nodes and chassis.
40
Remove the chassis PDB assembly
